System And Components
328-0054 WIRING GP-CAB -ROOFS/N NDC1-UP; YEG1-UP; A9J1-UP
Group No: 328-0054 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3S2093 | 1 STRAP-CABLE | 2 | |
| 7I2673 | 2 STRAP-CABLE | 2 | |
| 7Y5505 | 3 SPEAKER AS | 2 | |
| 7Y3951 | TERMINAL-BLADE (14-GA) | 2 | |
| 7Y3954 | CONNECTOR-PLUG (3-PIN) | 1 | |
| 1636795 | 4 STRAP-CABLE | 5 | |
| 2510637 | 5 INSULATION | 4 | |
| 3279967 | 6 HARNESS AS-CAB | 1 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 20-GA) | 5 | |
| 3S2093 | STRAP-CABLE | 14 | |
| 7Y3950 | TERMINAL-BLADE (14-GA TO 20-GA) | 4 | |
| 7Y3955 | CONNECTOR-RECEPTACLE | 2 | |
| 7Y3962 | TERMINAL-BULLET (MALE) | 2 | |
| 7Y3964 | TUBE | 2 | |
| 7Y3963 | TERMINAL-BULLET (FEMALE) | 2 | |
| 7Y3965 | TUBE | 2 | |
| 8T8737 | PLUG-SEAL | 4 | |
| 9W0852 | PIN-CONNECTOR (14-GA TO 16-GA) | 3 | |
| 1257875 | TUBE-HEAT SHRINK (7.44-MM DIA)(5-CM) | ||
| 2L8067 | TERMINAL-RING (10-GA TO 12-GA, 1/4-IN SCREW) | 2 | |
| 2L8075 | TERMINAL-RING (14-GA TO 16-GA, NO. 8 SCREW) | 1 | |
| 1673630 | CONNECTOR-PLUG | 1 | |
| 1673631 | TERMINAL (FEMALE) | 2 | |
| 2434510 | RECEPTACLE AS-CONNECTOR (12-PIN) | 1 | |
| 5P3059 | TERMINAL-FORK (18-GA TO 22-GA, NO. 6 SCREW) | 1 | |
| 4667113 | 7 ANTENNA AS | 1 | |
| 3423601 | 8 COVER AS | 1 | |
| 0966166 | 9 WASHER-HARD (4.5X9X1-MM THK) | 2 | |
| 1566175 | 10 CLIP (LADDER) | 1 | |
| 6V9491 | 11 SCREW-MACHINE (M4X0.7X20-MM) | 2 | |
| 8T0337 | 12 SCREW-MACHINE (M4X0.7X12-MM) | 6 | |
| 9X2042 | 13 SCREW-TRUSS HEAD (M6X1X12-MM) | 2 | |
| 1012846 | 14 GUARD (9-CM EACH) | ||
| 7K1181 | 15 STRAP-CABLE | 1 |
