377-8176 WIRING GP-CAB -REAR, RHS/N NDC1-UP; YEG1-UP

Group No: 377-8176 · Commonality

Part Number	Part Name	Qty
3S2093	1 STRAP-CABLE	3
7K1181	2 STRAP-CABLE	12
1673593	3 STRAP	1
2130772	4 SWITCH AS-MAGNETIC (24-VOLT)(MAIN RELAY)	1
2702679	5 LOCKWASHER	1
3068689	6 CABLE AS (MAIN FUSE RELAY)	1
6V2369	CABLE (4-GA, BLACK)(0.3-M)
9G4343	TERMINAL-RING (4-GA, 1/4-IN SCREW)	1
3258700	7 PLUG AS-CONNECTOR (12-PIN)	1
8T8737	PLUG-SEAL	12
2304009	PLUG AS-CONNECTOR (12-PIN)	1
4550709	SEAL-CONNECTOR	1
3280046	8 CABLE AS (MAIN POWER RELAY)	1
6V2369	CABLE (4-GA, BLACK)(0.2-M)
9G4343	TERMINAL-RING (4-GA, 1/4-IN SCREW)	1
3280060	9 BRACKET AS	1
3280186	10 BRACKET AS-BASE	1
3508462	11 CABLE AS (FUSE, RELAY PANEL)	1
6V2369	CABLE (4-GA, BLACK)(0.3-M)
9G4343	TERMINAL-RING (4-GA, 1/4-IN SCREW)	1
3245685	RECEPTACLE AS-CONNECTOR (1-PIN)	1
3280111	PIN-CONNECTOR	1
4314742	12 PANEL GP-FUSE (RELAY)	1
4596025	13 BRACKET	1
4906691	14 HARNESS AS-CAB (REAR RH)	1
5109643	15 PANEL AS-CONTROL (12/24-VOLT)	1
4831262	KNOB	1
0873796	16 SPACER (17.61X21.34X48-MM THK)	1
0950723	17 SCREW-SPECIAL (M3X0.5X10-MM)	1
0965962	18 WASHER-HARD (3.4X7X0.8-MM THK)	1
0966166	19 WASHER-HARD (4.5X9X1-MM THK)	4
1146658	20 WASHER (6.5X17X1-MM THK)	1
1566175	21 CLIP (LADDER)	6
1636795	22 STRAP-CABLE	1
2039007	23 NUT (1-1/2-18-THD)	1
4P7581	24 CLIP (LADDER)	3
5C2890	25 NUT (M6X1-THD)	1
5C9553	26 BOLT (M6X1X16-MM)	2
5P4115	27 WASHER-HARD (7.2X19X2-MM THK)	3
6V5210	28 SCREW-MACHINE (M4X0.7X10-MM)	4
7X2535	29 BOLT (M6X1X60-MM)	1
8T0328	30 WASHER-HARD (5.5X10X1-MM THK)	2
8T4753	31 SCREW (M5X0.8X20-MM)	2
9X2042	32 SCREW-TRUSS HEAD (M6X1X12-MM)	22
9X2046	33 SCREW-TRUSS HEAD (M6X1X35-MM)	4
9X8256	34 WASHER (6.6X12X2-MM THK)	3
9X2043	35 SCREW-TRUSS HEAD (M6X1X14-MM)	2
