System And Components
397-4672 WIRING GP-CAB -GRADE CONTROLS/N YEG1-UP; A9J1-UP
Group No: 397-4672 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3S2093 | 1 STRAP-CABLE | 7 | |
| 7K1181 | 2 STRAP-CABLE | 9 | |
| 3508498 | 3 HARNESS AS-PLATFORM | 1 | |
| 3422973 | CAP-CONNECTOR (3-PIN) | 1 | |
| 9X3401 | PIN-CONNECTOR (16-GA TO 18-GA) | 15 | |
| 1261767 | PIN-CONNECTOR (14-GA TO 16-GA) | 15 | |
| 2304009 | PLUG AS-CONNECTOR (12-PIN) | 1 | |
| 4550709 | SEAL-CONNECTOR | 1 | |
| 2304011 | PLUG AS-CONNECTOR (2-PIN) | 1 | |
| 4550704 | SEAL-CONNECTOR | 1 | |
| 2304013 | PLUG AS-CONNECTOR (3-PIN) | 1 | |
| 4550705 | SEAL-CONNECTOR | 1 | |
| 8T8737 | PLUG-SEAL | 1 | |
| 2434506 | RECEPTACLE AS-CONNECTOR (3-PIN) | 1 | |
| 3280076 | RECEPTACLE AS-CONNECTOR (12-PIN) | 1 | |
| 9X3402 | SOCKET-CONNECTOR (16-GA TO 18-GA) | 16 | |
| 1261768 | SOCKET-CONNECTOR (14-GA TO 16-GA) | 16 | |
| 3S2093 | STRAP-CABLE | 3 | |
| 1257874 | TUBE-HEAT SHRINK (5.72-MM DIA)(5-CM) | ||
| 4706293 | 4 HARNESS AS-CAB | 1 | |
| 4167158 | COVER-CONNECTOR | 1 | |
| 9W0852 | PIN-CONNECTOR (14-GA TO 16-GA) | 2 | |
| 9X3401 | PIN-CONNECTOR (16-GA TO 18-GA) | 18 | |
| 1261767 | PIN-CONNECTOR (14-GA TO 16-GA) | 18 | |
| 8T8737 | PLUG-SEAL | 17 | |
| 2304009 | PLUG AS-CONNECTOR (12-PIN) | 1 | |
| 4550709 | SEAL-CONNECTOR | 1 | |
| 3245678 | RESISTOR AS (120-OHM) | 2 | |
| 2647029 | SEAL-CONNECTOR | 1 | |
| 2434505 | RECEPTACLE AS-CONNECTOR (2-PIN) | 2 | |
| 2434509 | RECEPTACLE AS-CONNECTOR (8-PIN) | 1 | |
| 3245684 | RECEPTACLE AS-CONNECTOR (12-PIN) | 1 | |
| 9X3402 | SOCKET-CONNECTOR (16-GA TO 18-GA) | 30 | |
| 1261768 | SOCKET-CONNECTOR (14-GA TO 16-GA) | 30 | |
| 3S2093 | STRAP-CABLE | 11 | |
| 2L8077 | TERMINAL-RING (14-GA TO 16-GA, 1/4-IN SCREW) | 1 | |
| 1257874 | TUBE-HEAT SHRINK (5.72-MM DIA)(30-CM) | ||
| 1257875 | TUBE-HEAT SHRINK (7.44-MM DIA)(15-CM) | ||
| 1636795 | 5 STRAP-CABLE | 2 |
