Assembly
100%

453-8721 WIRING GP-CAB -QUICK COUPLERS/N NDC1-UP; YEG1-UP; A9J1-UP

Group No: 453-8721 · Commonality
Part NumberPart NameQty
7K11811 STRAP-CABLE9
25971802 COVER1
32804013 BRACKET1
33658804 SWITCH GP-TOGGLE (QUICK COUPLER)1
45387225 HARNESS AS-CAB (QUICK COUPLER)1
8T8729PIN-CONNECTOR (16-GA TO 20-GA)7
9X3401PIN-CONNECTOR (16-GA TO 18-GA)8
1261767PIN-CONNECTOR (14-GA TO 16-GA)8
2304009PLUG AS-CONNECTOR (12-PIN)1
2397356PLUG AS-CONNECTOR (12-PIN)1
4550709SEAL-CONNECTOR1
7Y3952PLUG-CONNECTOR (2-PIN)1
8T8737PLUG-SEAL49
1673542RECEPTACLE-CONNECTOR (5-PIN)1
2434507RECEPTACLE AS-CONNECTOR (4-PIN)1
2434510RECEPTACLE AS-CONNECTOR (12-PIN)1
2725000RECEPTACLE AS-CONNECTOR (12-PIN)1
3245684RECEPTACLE AS-CONNECTOR (12-PIN)1
3S2093STRAP-CABLE10
7Y3951TERMINAL-BLADE (14-GA)2
1673543TERMINAL (MALE)5
9X20426 SCREW-TRUSS HEAD (M6X1X12-MM)2
