System And Components
377-8251 WIRING GP-CHASSIS -CMB FCTN, ELEC CONT, ELEC RLFS/N NDC1-UP; YEG1-UP; A9J1-UP
Group No: 377-8251 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1114836 | 1 CLIP | 4 | |
| 1114837 | 2 CLIP | 1 | |
| 3508065 | 3 HARNESS AS-SENSOR (STICK OUT) | 1 | |
| 3422973 | CAP-CONNECTOR (3-PIN) | 1 | |
| 9X3401 | PIN-CONNECTOR (16-GA TO 18-GA) | 3 | |
| 1261767 | PIN-CONNECTOR (14-GA TO 16-GA) | 3 | |
| 2370227 | PLUG AS-CONNECTOR (3-PIN) | 1 | |
| 4450705 | SEAL-CONNECTOR | 1 | |
| 2434506 | RECEPTACLE AS-CONNECTOR (3-PIN) | 1 | |
| 9X3402 | SOCKET-CONNECTOR (16-GA TO 18-GA) | 3 | |
| 1261768 | SOCKET-CONNECTOR (14-GA TO 16-GA) | 3 | |
| 4842948 | 4 HARNESS AS-CHASSIS (CAB BULKHEAD) | 1 | |
| 0919035 | 5 SPACER (11X25X20-MM THK) | 1 | |
| 1325789 | 6 CLIP (LADDER) | 1 | |
| 1772215 | 7 STRAP-DUAL CLAMP | 3 | |
| 3S2093 | 8 STRAP-CABLE | 28 | |
| 4P7428 | 9 CLIP (LADDER) | 1 | |
| 4P7581 | 10 CLIP (LADDER) | 2 | |
| 5P4116 | 11 WASHER-HARD (8.8X20.5X2-MM THK) | 1 | |
| 7K1181 | 12 STRAP-CABLE | 27 | |
| 8T4121 | 13 WASHER-HARD (11X21X2.5-MM THK) | 6 | |
| 8T4137 | 14 BOLT (M10X1.5X20-MM) | 4 | |
| 8T4182 | 15 BOLT (M10X1.5X45-MM) | 1 | |
| 8T4191 | 16 BOLT (M10X1.5X16-MM) | 1 | |
| 8T4200 | 17 BOLT (M8X1.25X16-MM) | 1 |
