377-8252 WIRING GP-CHASSISS/N YEG1-UP; A9J1-UP

Group No: 377-8252 · Commonality

Part Number	Part Name	Qty
3S2093	1 STRAP-CABLE	28
7K1181	2 STRAP-CABLE	20
1114836	3 CLIP	3
1114837	4 CLIP	1
1772215	5 STRAP-DUAL CLAMP	3
3508065	6 HARNESS AS-SENSOR (STICK OUT)	1
3422973	CAP-CONNECTOR (3-PIN)	1
9X3401	PIN-CONNECTOR (16-GA TO 18-GA)	3
1261767	PIN-CONNECTOR (14-GA TO 16-GA)	3
2370227	PLUG AS-CONNECTOR (3-PIN)	1
4450705	SEAL-CONNECTOR	1
2434506	RECEPTACLE AS-CONNECTOR (3-PIN)	1
9X3402	SOCKET-CONNECTOR (16-GA TO 18-GA)	3
1261768	SOCKET-CONNECTOR (14-GA TO 16-GA)	3
3886741	7 HARNESS AS-CHASSIS (CAB BULKHEAD)	1
3422972	CAP-CONNECTOR (2-PIN)	3
3422973	CAP-CONNECTOR (3-PIN)	3
8T8729	PIN-CONNECTOR (16-GA TO 20-GA)	3
1552270	KIT-CONNECTING PLUG (2-PIN)	8
2304009	PLUG AS-CONNECTOR (12-PIN)	3
4550709	SEAL-CONNECTOR	1
2304011	PLUG AS-CONNECTOR (2-PIN)	3
4550704	SEAL-CONNECTOR	1
2304013	PLUG AS-CONNECTOR (3-PIN)	2
2370227	PLUG AS-CONNECTOR (3-PIN)	1
4450705	SEAL-CONNECTOR	1
8T8737	PLUG-SEAL	43
2434510	RECEPTACLE AS-CONNECTOR (12-PIN)	1
1028802	KIT-RECEPTACLE (2-PIN)	8
8T8730	SOCKET-CONNECTOR (16-GA TO 20-GA)	33
9X3402	SOCKET-CONNECTOR (16-GA TO 18-GA)	16
1261768	SOCKET-CONNECTOR (14-GA TO 16-GA)	16
3S2093	STRAP-CABLE	7
2L8079	TERMINAL-RING (14-GA TO 16-GA, 3/8-IN SCREW)	1
1257874	TUBE-HEAT SHRINK (5.72-MM DIA)(25-CM)
1257875	TUBE-HEAT SHRINK (7.44-MM DIA)(15-CM)
0919035	8 SPACER (11X25X20-MM THK)	1
4P7581	9 CLIP (LADDER)	1
5P4116	10 WASHER-HARD (8.8X20.5X2-MM THK)	1
8T4121	11 WASHER-HARD (11X21X2.5-MM THK)	4
8T4137	12 BOLT (M10X1.5X20-MM)	3
8T4182	13 BOLT (M10X1.5X45-MM)	1
8T4200	14 BOLT (M8X1.25X16-MM)	1
