System And Components
377-8257 WIRING GP-CHASSIS -REFUELING PUMPS/N NDC1-UP
Group No: 377-8257 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3S2093 | 1 STRAP-CABLE | 21 | |
| 7K1181 | 2 STRAP-CABLE | 11 | |
| 9X3495 | 3 CLIP AS | 1 | |
| 8C3334 | RIVET-TUBULAR | 2 | |
| 3122645 | 4 SWITCH AS-LIQUID LEVEL (FUEL TANK SHUTOFF) | 1 | |
| 2S4078 | SEAL-O-RING | 1 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 20-GA) | 2 | |
| 2434505 | RECEPTACLE AS-CONNECTOR (2-PIN) | 1 | |
| 3245761 | 5 COVER AS | 1 | |
| 1211029 | CLIP | 1 | |
| 3640255 | 6 HARNESS AS-FUEL TANK | 1 | |
| 8T8730 | SOCKET-CONNECTOR (16-GA TO 20-GA) | 4 | |
| 2304011 | PLUG AS-CONNECTOR (2-PIN) | 2 | |
| 4550704 | SEAL-CONNECTOR | 1 | |
| 4327418 | 7 HARNESS AS-PUMP | 1 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 20-GA) | 2 | |
| 8T8730 | SOCKET-CONNECTOR (16-GA TO 20-GA) | 2 | |
| 3S2093 | STRAP-CABLE | 1 | |
| 1160126 | HOUSING-PLUG | 2 | |
| 1160128 | SEAL | 2 | |
| 1160255 | TERMINAL-BLADE (10-GA TO 20-GA) | 4 | |
| 2L8069 | TERMINAL-RING (2-GA TO 10-GA, 3/8-IN SCREW) | 1 | |
| 2L8079 | TERMINAL-RING (14-GA TO 16-GA, 3/8-IN SCREW) | 1 | |
| 2304011 | PLUG AS-CONNECTOR (2-PIN) | 1 | |
| 4550704 | SEAL-CONNECTOR | 1 | |
| 2434505 | RECEPTACLE AS-CONNECTOR (2-PIN) | 1 | |
| 3245750 | PLUG AS-CONNECTOR | 1 | |
| 1325789 | 8 CLIP (LADDER) | 1 | |
| 4P7581 | 9 CLIP (LADDER) | 1 | |
| 6G2263 | 10 SPACER (10.5X19X28.5-MM THK) | 1 | |
| 8T4121 | 11 WASHER-HARD (11X21X2.5-MM THK) | 1 | |
| 8T4179 | 12 BOLT (M12X1.75X20-MM) | 2 | |
| 8T4182 | 13 BOLT (M10X1.5X45-MM) | 1 | |
| 8T4223 | 14 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 8T4137 | 15 BOLT (M10X1.5X20-MM) | 1 |
