System And Components
388-6759 WIRING GP-CHASSIS -GRADE CONTROLS/N A9J1-UP
Group No: 388-6759 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1114836 | 1 CLIP | 5 | |
| 1114837 | 2 CLIP | 5 | |
| 4451395 | 3 BRACKET AS | 1 | |
| 4861087 | 4 HARNESS AS-CHASSIS | 1 | |
| 8T8730 | SOCKET-CONNECTOR (16-GA TO 20-GA) | 1 | |
| 3S2093 | STRAP-CABLE | 6 | |
| 8T8737 | PLUG-SEAL | 90 | |
| 9W1951 | RECEPTACLE AS-CONNECTOR (9-PIN) | 1 | |
| 1193662 | TUBE-HEAT SHRINK (10.85-MM DIA)(13-CM) | ||
| 1257874 | TUBE-HEAT SHRINK (5.72-MM DIA)(140-CM) | ||
| 1257875 | TUBE-HEAT SHRINK (7.44-MM DIA)(10-CM) | ||
| 9X3402 | SOCKET-CONNECTOR (16-GA TO 18-GA) | 42 | |
| 1261768 | SOCKET-CONNECTOR (14-GA TO 16-GA) | 42 | |
| 2L8069 | TERMINAL-RING (2-GA TO 10-GA, 3/8-IN SCREW) | 2 | |
| 9X3401 | PIN-CONNECTOR (16-GA TO 18-GA) | 41 | |
| 1261767 | PIN-CONNECTOR (14-GA TO 16-GA) | 41 | |
| 1552256 | KIT-CONNECTING PLUG (12-PIN) | 1 | |
| 1552260 | KIT-CONNECTING PLUG (3-PIN) | 1 | |
| 1907614 | KIT-RECEPTACLE (12-PIN) | 1 | |
| 3704059 | KIT-RECEPTACLE (12-PIN) | 1 | |
| 2304009 | PLUG AS-CONNECTOR (12-PIN) | 5 | |
| 4550709 | SEAL-CONNECTOR | 1 | |
| 2370166 | KIT-CONNECTING PLUG (12-PIN) | 1 | |
| 2434505 | RECEPTACLE AS-CONNECTOR (2-PIN) | 3 | |
| 2434510 | RECEPTACLE AS-CONNECTOR (12-PIN) | 3 | |
| 2532695 | PLUG AS-CONNECTOR (6-PIN) | 1 | |
| 2628088 | HOSE (80-CM) | ||
| 3245678 | RESISTOR AS (120-OHM) | 2 | |
| 2647029 | SEAL-CONNECTOR | 1 | |
| 1552258 | WEDGE-PLUG LOCK (12-PIN) | 2 | |
| 8C6354 | CAP-RECEPTACLE (ET CONNECTOR) | 1 | |
| 1325789 | 5 CLIP (LADDER) | 2 | |
| 2S1647 | 6 GROMMET | 1 | |
| 3371205 | 7 GROMMET | 1 | |
| 3S2093 | 8 STRAP-CABLE | 30 | |
| 4I3953 | 9 GROMMET | 1 | |
| 7K1181 | 10 STRAP-CABLE | 35 | |
| 8T4121 | 11 WASHER-HARD (11X21X2.5-MM THK) | 9 | |
| 8T4137 | 12 BOLT (M10X1.5X20-MM) | 8 | |
| 8T4198 | 13 BOLT (M10X1.5X100-MM) | 1 | |
| 3508388 | 14 SPACER (11X25X65-MM THK) | 1 |
