System And Components
499-2157 WIRING GP-CHASSISS/N NDC1-UP; YEG10001-UP; A9J10001-UP
Group No: 499-2157 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3S2093 | 1 STRAP-CABLE | 29 | |
| 7K1181 | 2 STRAP-CABLE | 19 | |
| 1114836 | 3 CLIP | 3 | |
| 1114837 | 4 CLIP | 1 | |
| 5039060 | 5 HARNESS AS-CHASSIS (SMARTBOOM) | 1 | |
| 5043690 | 6 HARNESS AS-VALVE | 1 | |
| 1261768 | SOCKET-CONNECTOR (14-GA TO 16-GA) | 3 | |
| 9X3402 | SOCKET-CONNECTOR (16-GA TO 18-GA) | 3 | |
| 9X3401 | PIN-CONNECTOR (16-GA TO 18-GA) | 3 | |
| 1261767 | PIN-CONNECTOR (14-GA TO 16-GA) | 3 | |
| 2434506 | RECEPTACLE AS-CONNECTOR (3-PIN) | 1 | |
| 2818803 | PLUG AS-CONNECTOR (3-PIN) | 1 | |
| 4550705 | SEAL-CONNECTOR | 1 | |
| 0919035 | 7 SPACER (11X25X20-MM THK) | 1 | |
| 2041611 | 8 STRAP-CABLE (DUAL) | 2 | |
| 1772215 | 9 STRAP-DUAL CLAMP | 2 | |
| 4P7581 | 10 CLIP (LADDER) | 1 | |
| 5P4116 | 11 WASHER-HARD (8.8X20.5X2-MM THK) | 1 | |
| 8T4121 | 12 WASHER-HARD (11X21X2.5-MM THK) | 4 | |
| 8T4137 | 13 BOLT (M10X1.5X20-MM) | 3 | |
| 8T4182 | 14 BOLT (M10X1.5X45-MM) | 1 | |
| 8T4200 | 15 BOLT (M8X1.25X16-MM) | 1 |
