System And Components
499-2160 WIRING GP-CHASSIS -QUICK COUPLER, HIGH PRESSURES/N NDC1-UP; YEG1-UP; A9J1-UP
Group No: 499-2160 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3S2093 | 1 STRAP-CABLE | 14 | |
| 7K1181 | 2 STRAP-CABLE | 12 | |
| 2667379 | 3 STRAP-CABLE | 1 | |
| 5039062 | 4 HARNESS AS-CHASSIS | 1 | |
| 8T8730 | SOCKET-CONNECTOR (16-GA TO 20-GA) | 6 | |
| 3S2093 | STRAP-CABLE | 1 | |
| 8T8737 | PLUG-SEAL | 4 | |
| 9X3402 | SOCKET-CONNECTOR (16-GA TO 18-GA) | 12 | |
| 1261768 | SOCKET-CONNECTOR (14-GA TO 16-GA) | 12 | |
| 2L8079 | TERMINAL-RING (14-GA TO 16-GA, 3/8-IN SCREW) | 1 | |
| 2304009 | PLUG AS-CONNECTOR (12-PIN) | 1 | |
| 4550709 | SEAL-CONNECTOR | 1 | |
| 2304011 | PLUG AS-CONNECTOR (2-PIN) | 2 | |
| 4550704 | SEAL-CONNECTOR | 1 | |
| 2304013 | PLUG AS-CONNECTOR (3-PIN) | 2 | |
| 4550705 | SEAL-CONNECTOR | 1 | |
| 5039063 | 5 HARNESS AS-SENSOR (COUPLER) | 1 | |
| 9X3402 | SOCKET-CONNECTOR (16-GA TO 18-GA) | 3 | |
| 1261768 | SOCKET-CONNECTOR (14-GA TO 16-GA) | 3 | |
| 9X3401 | PIN-CONNECTOR (16-GA TO 18-GA) | 3 | |
| 1261767 | PIN-CONNECTOR (14-GA TO 16-GA) | 1 | |
| 2434506 | RECEPTACLE AS-CONNECTOR (3-PIN) | 1 | |
| 2818803 | PLUG AS-CONNECTOR (3-PIN) | 1 | |
| 4550705 | SEAL-CONNECTOR | 1 | |
| 2041611 | 6 STRAP-CABLE (DUAL) | 1 | |
| 3474734 | 7 CLIP | 1 | |
| 8T4121 | 8 WASHER-HARD (11X21X2.5-MM THK) | 1 | |
| 8T4191 | 9 BOLT (M10X1.5X16-MM) | 1 |
