Assembly
100%

479-7817 WIRING GP-CONSOLE -RHS/N NDC10001-UP; YEG10001-UP; A9J10001-UP

Group No: 479-7817 · Commonality
Part NumberPart NameQty
7K11811 STRAP-CABLE2
32457322 BRACKET1
47978223 HARNESS AS-CONSOLE (RH)1
3S2093STRAP-CABLE4
7Y3967TERMINAL AS2
7Y3963TERMINAL-BULLET (FEMALE)1
7Y3965TUBE1
9X3402SOCKET-CONNECTOR (16-GA TO 18-GA)6
1261768SOCKET-CONNECTOR (14-GA TO 16-GA)6
9X3401PIN-CONNECTOR (16-GA TO 18-GA)8
1261767PIN-CONNECTOR (14-GA TO 16-GA)8
2397352PLUG AS-CONNECTOR (6-PIN)1
4550707SEAL-CONNECTOR1
2434509RECEPTACLE AS-CONNECTOR (8-PIN)1
3422974CAP-CONNECTOR (6-PIN)1
9X20424 SCREW-TRUSS HEAD (M6X1X12-MM)2
