System And Components
336-6020 WIRING GP-FRONT -GRADE CONTROL, BOOMPART OF 344-0819, 527-7133 BOOM AR-REACH
Group No: 336-6020 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3S2093 | 1 STRAP-CABLE | 17 | |
| 1114836 | 2 CLIP | 7 | |
| 1114837 | 3 CLIP | 3 | |
| 1160118 | 4 CLIP | 2 | |
| 1404767 | 5 CLAMP-HOSE | 1 | |
| 4820924 | 6 HARNESS AS-SENSOR | 1 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 20-GA) | 1 | |
| 8T8730 | SOCKET-CONNECTOR (16-GA TO 20-GA) | 1 | |
| 8T8737 | PLUG-SEAL | 5 | |
| 1257874 | TUBE-HEAT SHRINK (5.72-MM DIA)(5-CM) | ||
| 1257875 | TUBE-HEAT SHRINK (7.44-MM DIA)(5-CM) | ||
| 9X3402 | SOCKET-CONNECTOR (16-GA TO 18-GA) | 11 | |
| 1261768 | SOCKET-CONNECTOR (14-GA TO 16-GA) | 11 | |
| 9X3401 | PIN-CONNECTOR (16-GA TO 18-GA) | 9 | |
| 1261767 | PIN-CONNECTOR (14-GA TO 16-GA) | 9 | |
| 1552260 | KIT-CONNECTING PLUG (3-PIN) | 1 | |
| 2304009 | PLUG AS-CONNECTOR (12-PIN) | 1 | |
| 2647034 | SEAL-CONNECTOR | 1 | |
| 2434510 | RECEPTACLE AS-CONNECTOR (12-PIN) | 1 | |
| 2628088 | HOSE (190-CM) | ||
| 1114838 | 7 CLIP | 2 | |
| 1274471 | 8 CLAMP-HOSE | 1 | |
| 2041611 | 9 STRAP-CABLE (DUAL) | 10 | |
| 6D3479 | 10 CLIP (LOOP) | 1 | |
| 8T4121 | 11 WASHER-HARD (11X21X2.5-MM THK) | 5 | |
| 8T4133 | 12 NUT (M10X1.5-THD) | 2 | |
| 8T4136 | 13 BOLT (M10X1.5X25-MM) | 1 | |
| 8T4137 | 14 BOLT (M10X1.5X20-MM) | 1 | |
| 8T4191 | 15 BOLT (M10X1.5X16-MM) | 1 | |
| 8T4195 | 16 BOLT (M10X1.5X30-MM) | 1 |
