319-0878 WIRING GP-PLATFORMS/N NDC1-UP; YEG1-UP; A9J1-10000

Group No: 319-0878 · Commonality
Part NumberPart NameQty
3E51691 GUARD-SWITCH1
3S20932 STRAP-CABLE14
6S40393 GROMMET1
7G10604 STRAP AS-GROUND1
7K11815 STRAP-CABLE5
11148366 CLIP7
11148377 CLIP1
11601188 CLIP6
23411229 COVER1
301298110 SWITCH AS-TOGGLE (SECONDARY SHUTDOWN)1
1028803KIT-RECEPTACLE (3-PIN)1
8T8729PIN-CONNECTOR (16-GA TO 20-GA)3
6T3631NUT-HEX (15/32-32-THD)2
6T3632LOCKWASHER1
6T3633RING-LOCKING1
360629111 HARNESS AS-PLATFORM1
1028804KIT-RECEPTACLE (4-PIN)1
8T8729PIN-CONNECTOR (16-GA TO 20-GA)3
8T8730SOCKET-CONNECTOR (16-GA TO 20-GA)3
3S2093STRAP-CABLE15
8T8737PLUG-SEAL5
9W0852PIN-CONNECTOR (14-GA TO 16-GA)8
9W0844SOCKET-CONNECTOR (14-GA TO 16-GA)5
1257875TUBE-HEAT SHRINK (7.44-MM DIA)(20-CM)
9X3402SOCKET-CONNECTOR (16-GA TO 18-GA)24
2L8069TERMINAL-RING (2-GA TO 10-GA, 3/8-IN SCREW)3
9X3401PIN-CONNECTOR (16-GA TO 18-GA)13
1552271KIT-CONNECTING PLUG (4-PIN)1
1552260KIT-CONNECTING PLUG (3-PIN)1
2304011PLUG AS-CONNECTOR (2-PIN)5
2647029SEAL-CONNECTOR1
2304013PLUG AS-CONNECTOR (3-PIN)1
2647030SEAL-CONNECTOR1
2305008PLUG AS-CONNECTOR (4-PIN)1
2647031SEAL-CONNECTOR1
2370227PLUG AS-CONNECTOR (3-PIN)3
2647030SEAL-CONNECTOR1
3280076RECEPTACLE AS-CONNECTOR (12-PIN)2
3422972CAP-CONNECTOR (2-PIN)5
3422973CAP-CONNECTOR (3-PIN)4
3422978CAP-CONNECTOR (4-PIN)1
319126012 PANEL2
328007713 CAP2
328011914 SHEET1
096616615 WASHER-HARD (4.5X9X1-MM THK)2
132578916 CLIP (LADDER)3
7X262118 BOLT (M10X1.5X12-MM)6
8T033719 SCREW-MACHINE (M4X0.7X12-MM)2
8T412120 WASHER-HARD (11X21X2.5-MM THK)21
8T413621 BOLT (M10X1.5X25-MM)4
8T413722 BOLT (M10X1.5X20-MM)8
8T419123 BOLT (M10X1.5X16-MM)3
204161124 STRAP-CABLE (DUAL)1
