System And Components
335-0071 CONTROL GP-FOOT -FOOT SWITCH, ON/OFF, LHS/N YEG1-UP; A9J1-UP
Group No: 335-0071 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0932069 | 1 GROMMET | 1 | |
| 9X2038 | 2 WASHER (7X19X2-MM THK) | 2 | |
| 3378541 | 3 SUPPORT AS | 1 | |
| 3378542 | 4 SUPPORT AS | 1 | |
| 3491841 | 5 PLATE-STOP | 1 | |
| 0992374 | 6 BOLT-SOCKET HEAD (M5X0.8X12-MM) | 2 | |
| 8T0269 | 7 BOLT-SOCKET HEAD (M6X1X20-MM) | 2 | |
| 8T4121 | 8 WASHER-HARD (11X21X2.5-MM THK) | 4 | |
| 8T4137 | 9 BOLT (M10X1.5X20-MM) | 4 | |
| 2Q4703 | 10 SWITCH AS-FOOT PEDAL (FOOT SWITCH, ON/OFF, LH) | 1 | |
| 2051340 | HARNESS AS-OPERATOR CONTROLS | 1 | |
| 8T8730 | SOCKET-CONNECTOR (16-GA TO 20-GA) | 2 | |
| 2L8075 | TERMINAL-RING (14-GA TO 16-GA, NO. 8 SCREW) | 2 | |
| 1552270 | KIT-CONNECTING PLUG (2-PIN) | 1 |
