System And Components
505-6169 LINES GP-AIR -LANDFILLS/N E6N1-UP
Group No: 505-6169
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2W7111 | 1 FLANGE | 2 | |
| 4W3851 | 2 BRACKET | 2 | |
| 4W9725 | 3 GASKET | 2 | |
| 4W9726 | 4 FLANGE | 1 | |
| 7L4302 | 5 GASKET | 2 | |
| 1213342 | 6 PIPE (LH) | 1 | |
| 1688506 | 7 PIPE (RH) | 1 | |
| 1973306 | 8 ADAPTER | 1 | |
| 3307151 | 9 HOSE AS | 1 | |
| 0321267 | 10 CONNECTOR (STRAIGHT) | 1 | |
| 0321268 | 11 CONNECTOR (90-DEG) | 1 | |
| 1A2029 | 12 BOLT (3/8-16X1.125-IN) | 2 | |
| 1A5822 | 13 BOLT (1/2-13X2.75-IN) | 2 | |
| 5P8245 | 14 WASHER-HARD (13.5X25.5X3-MM THK) | 14 | |
| 5P8862 | 15 SEAL-O-RING | 2 | |
| 6V2695 | 16 SEAL-O-RING | 4 | |
| 6V3917 | 17 SEAL-O-RING | 4 | |
| 7B3235 | 18 BOLT (1/2-13X1.375-IN) | 6 | |
| 8T6765 | 19 PLUG-PIPE (1/4-18-THD) | 1 | |
| 9S1366 | 20 BOLT (1/2-13X2.5-IN) | 6 | |
| 9X6458 | 21 WASHER-HARD (10.2X22.5X3-MM THK) | 2 |
