System And Components
396-9045 AFTERCOOLER GP-WATERS/N E661-UP
Group No: 396-9045
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3B9067 | 1 COCK-DRAIN | 2 | |
| 1213339 | 2 SUPPORT | 1 | |
| 1229785 | 3 BRACKET | 1 | |
| 1285423 | 4 HOUSING (AFTERCOOLER) | 1 | |
| 1285424 | 5 HOUSING (AFTERCOOLER) | 1 | |
| 1285425 | 6 PLATE | 1 | |
| 1525705 | 7 GASKET | 2 | |
| 1978675 | 8 AFTERCOOLER GP-WATER | 1 | |
| 0L1143 | 9 BOLT (3/8-16X2.5-IN) | 4 | |
| 0S1590 | 10 BOLT (3/8-16X2-IN) | 4 | |
| 1A2029 | 11 BOLT (3/8-16X1.125-IN) | 8 | |
| 1T0720 | 12 BOLT-12 POINT HEAD (3/8-16X1.25-IN) | 63 | |
| 2Y5882 | 13 ELBOW | 2 | |
| 3B1915 | 14 BOLT (3/8-16X1.375-IN) | 6 | |
| 5M2894 | 15 WASHER-HARD (10.2X18.5X2.5-MM THK) | 15 | |
| 5P7701 | 16 SEAL-O-RING | 1 | |
| 5P0076 | 17 BOLT-12 POINT HEAD (3/8-16X1.5-IN) | 5 | |
| 7X4810 | 18 SEAL-O-RING | 2 | |
| 8L2786 | 19 SEAL-O-RING | 4 | |
| 8T6764 | 20 PLUG-PIPE (1/8-27-THD) | 2 | |
| 8T6765 | 21 PLUG-PIPE (1/4-18-THD) | 4 | |
| 9L9132 | 22 WASHER-HARD (10.2X25.5X2.5-MM THK) | 18 | |
| 9S4181 | 23 PLUG (1-5/16-12-THD) | 1 | |
| 9S4185 | 24 PLUG (3/4-16-THD) | 4 | |
| 9S8752 | 25 NUT-FULL (3/8-16-THD) | 10 | |
| 9X6138 | 26 PLUG-PIPE | 1 | |
| 7G1239 | 27 SPACER (10.5X19X4.5-MM THK) | 5 |
