System And Components
379-4861 AFTERCOOLER GP-AIRS/N E6R1-UP
Group No: 379-4861
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4W9852 | 1 HOUSING-REAR (AFTERCOOLER) | 1 | |
| 7E1823 | 2 HOUSING-FRONT (AFTERCOOLER) | 1 | |
| 1213339 | 3 SUPPORT | 1 | |
| 1217543 | 4 PLATE | 1 | |
| 1229785 | 5 BRACKET | 1 | |
| 1525705 | 6 GASKET | 2 | |
| 0L1143 | 7 BOLT (3/8-16X2.5-IN) | 4 | |
| 0S1571 | 8 BOLT (3/8-16X1.75-IN) | 4 | |
| 0S1594 | 9 BOLT (3/8-16X1-IN) | 68 | |
| 1A2029 | 10 BOLT (3/8-16X1.125-IN) | 8 | |
| 3B1915 | 11 BOLT (3/8-16X1.375-IN) | 6 | |
| 5M2894 | 12 WASHER-HARD (10.2X18.5X2.5-MM THK) | 10 | |
| 5P7701 | 13 SEAL-O-RING | 1 | |
| 6V8801 | 14 NUT (3/8-16-THD) | 4 | |
| 8L2786 | 16 SEAL-O-RING | 3 | |
| 8T6765 | 17 PLUG-PIPE (1/4-18-THD) | 1 | |
| 9L9132 | 18 WASHER-HARD (10.2X25.5X2.5-MM THK) | 18 | |
| 9S4181 | 19 PLUG (1-5/16-12-THD) | 1 | |
| 9S4185 | 20 PLUG (3/4-16-THD) | 3 | |
| 9S8752 | 21 NUT-FULL (3/8-16-THD) | 6 |
