Assembly
100%

306-9149 WIRING GP-ENGINEAN ATTACHMENT

Group No: 306-9149
Part NumberPart NameQty
2P89771 PLATE1
2S23012 SPACER (0.344X0.75X0.646-IN THK)1
4W91493 SPACER (10.5X19X16.75-MM THK)1
9X34954 CLIP AS1
8C3334RIVET-TUBULAR2
8V97085 SPACER (14.3X25.4X35-MM THK)1
9S32326 CLIP2
39183477 HARNESS AS-ENGINE1
20422818 STRAP-CABLE1
17817819 CLIP1
9X677210 STRAP-CABLE36
251938911 BRACKET1
7K118112 STRAP-CABLE8
0L135113 BOLT (3/8-16X0.875-IN)1
0L135214 BOLT (3/8-16X3.25-IN)1
0S050915 BOLT (3/8-16X0.75-IN)13
165392916 BOLT (3/8-16X1.5-IN)1
0S159417 BOLT (3/8-16X1-IN)4
132578918 CLIP (LADDER)2
230773219 MOUNTING-CABLE TIE1
4P758120 CLIP (LADDER)3
4P813421 CLIP (LADDER)32
5M289422 WASHER-HARD (10.2X18.5X2.5-MM THK)24
5P824523 WASHER-HARD (13.5X25.5X3-MM THK)1
5S000324 NUT (5/16-18-THD)1
6B620525 SPACER (0.438X0.875X1.281-IN THK)4
7X029126 BOLT (3/8-16X3.75-IN)2
9L913227 WASHER-HARD (10.2X25.5X2.5-MM THK)4
9N086928 WASHER-HARD (8.8X25.5X2-MM THK)2
9S875229 NUT-FULL (3/8-16-THD)4
9X645830 WASHER-HARD (10.2X22.5X3-MM THK)1
0L132931 BOLT (1/2-13X3-IN)1
9X677233 STRAP-CABLE1
0S159034 BOLT (3/8-16X2-IN)1
4P813435 CLIP (LADDER)1
5M289436 WASHER-HARD (10.2X18.5X2.5-MM THK)1
9X677237 STRAP-CABLE1
4P758138 CLIP (LADDER)1
0S159539 BOLT (1/2-13X1.25-IN)2
1F795840 NUT-FULL (1/2-13-THD)2
4P742941 CLIP (LADDER)2
5P824542 WASHER-HARD (13.5X25.5X3-MM THK)4
9X677243 STRAP-CABLE5
4P813444 CLIP (LADDER)5
