System And Components
377-9657 LINES GP-TURBOCHARGER WATERPART OF 481-6506 ENGINE AR-COMPLETE
Group No: 377-9657
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6P7053 | 1 CLAMP | 6 | |
| 7N3297 | 2 COVER | 1 | |
| 7N3368 | 3 GASKET | 1 | |
| 7N7878 | 4 PLATE-COVER | 4 | |
| 1070744 | 5 BLOCK | 4 | |
| 1381490 | 6 SPACER (10.2X18X15-MM THK) | 1 | |
| 1400395 | 7 SPACER (10.74X17.14X11-MM THK) | 1 | |
| 1994673 | 8 CONNECTOR | 1 | |
| 3779658 | 9 HOSE AS | 1 | |
| 3779659 | 10 HOSE AS | 2 | |
| 3779660 | 11 HOSE AS | 1 | |
| 3779661 | 12 TUBE AS | 1 | |
| 3779662 | 13 TUBE AS | 1 | |
| 3779663 | 14 HOSE AS | 1 | |
| 3779664 | 15 TUBE AS | 1 | |
| 3779665 | 16 HOSE AS | 1 | |
| 3779666 | 17 TUBE AS | 1 | |
| 3779667 | 18 HOSE AS | 1 | |
| 3779668 | 19 HOSE AS | 1 | |
| 3902907 | 20 BRACKET | 1 | |
| 3982210 | 21 BRACKET | 1 | |
| 3982211 | 22 BLOCK | 1 | |
| 3982212 | 23 BRACKET | 1 | |
| 3982213 | 24 BRACKET | 1 | |
| 3982214 | 25 BLOCK | 1 | |
| 3982216 | 26 BRACKET | 1 | |
| 0619593 | 27 ADAPTER | 1 | |
| 0909019 | 28 PLUG-PIPE (1-11-1/2 NPT THD) | 1 | |
| 1653931 | 29 BOLT (3/8-16X1.75-IN) | 2 | |
| 0S1588 | 30 BOLT (3/8-16X1.25-IN) | 2 | |
| 1653929 | 31 BOLT (3/8-16X1.5-IN) | 8 | |
| 0S1594 | 32 BOLT (3/8-16X1-IN) | 15 | |
| 0S1615 | 33 BOLT (1/4-20X0.75-IN) | 3 | |
| 1345645 | 34 CLIP | 2 | |
| 1448618 | 35 ADAPTER | 1 | |
| 1A2029 | 36 BOLT (3/8-16X1.125-IN) | 2 | |
| 1C2251 | 37 BOLT (3/8-16X1.87-IN) | 2 | |
| 1F7958 | 38 NUT-FULL (1/2-13-THD) | 2 | |
| 2T2396 | 39 ELBOW | 1 | |
| 3159833 | 40 CONNECTOR | 1 | |
| 3419211 | 41 GASKET | 8 | |
| 3B1915 | 42 BOLT (3/8-16X1.375-IN) | 2 | |
| 3D2824 | 43 SEAL-O-RING | 5 | |
| 3E2333 | 44 ELBOW | 1 | |
| 3J5390 | 45 PLUG (3/8-18-THD) | 1 | |
| 3K0360 | 46 SEAL-O-RING | 8 | |
| 4K8302 | 47 CLIP (LOOP) | 3 | |
| 5L4759 | 48 SEAL-O-RING | 1 | |
| 5M2894 | 49 WASHER-HARD (10.2X18.5X2.5-MM THK) | 37 | |
| 5P0537 | 50 WASHER-HARD (7.2X14.5X2-MM THK) | 6 | |
| 5P8245 | 51 WASHER-HARD (13.5X25.5X3-MM THK) | 6 | |
| 5P9299 | 52 CLIP (LOOP) | 4 | |
| 6H1717 | 53 BOLT (1/2-13X1.125-IN) | 1 | |
| 6V8398 | 54 SEAL-O-RING | 21 | |
| 6V8637 | 55 CONNECTOR | 2 | |
| 6V8639 | 56 CONNECTOR | 6 | |
| 6V8714 | 57 CONNECTOR | 1 | |
| 6V8789 | 58 TEE | 1 | |
| 6V9002 | 59 ELBOW | 2 | |
| 6V9746 | 60 SEAL-O-RING | 4 | |
| 6V9830 | 61 CAP (ORFS) | 1 | |
| 6V9837 | 62 TEE-SWIVEL | 2 | |
| 7B3235 | 63 BOLT (1/2-13X1.375-IN) | 1 | |
| 7H1911 | 64 BOLT (1/2-13X9.375-IN) | 2 | |
| 8C6868 | 65 CONNECTOR | 1 | |
| 8C6871 | 66 CONNECTOR | 1 | |
| 8C6872 | 67 CONNECTOR | 1 | |
| 8C6874 | 68 CONNECTOR | 1 | |
| 8T5429 | 69 ELBOW | 2 | |
| 9S8750 | 70 NUT-FULL (1/4-20-THD) | 3 | |
| 9S8752 | 71 NUT-FULL (3/8-16-THD) | 4 | |
| 6V8397 | 72 SEAL-O-RING | 1 | |
| 7M8485 | 73 SEAL-O-RING | 1 | |
| 5K9090 | 74 SEAL-O-RING | 1 |
