System And Components
487-8083 LINES GP-TURBOCHARGER WATERAN ATTACHMENT
Group No: 487-8083
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7N3297 | 1 COVER | 1 | |
| 7N3368 | 2 GASKET | 1 | |
| 7N7878 | 3 PLATE-COVER | 4 | |
| 1070744 | 4 BLOCK | 4 | |
| 1994673 | 5 CONNECTOR | 1 | |
| 3419211 | 6 GASKET | 8 | |
| 3779658 | 7 HOSE AS | 1 | |
| 3779659 | 8 HOSE AS | 2 | |
| 3779660 | 9 HOSE AS | 1 | |
| 3779661 | 10 TUBE AS | 1 | |
| 3779662 | 11 TUBE AS | 1 | |
| 3779663 | 12 HOSE AS | 1 | |
| 3779665 | 13 HOSE AS | 1 | |
| 3779666 | 14 TUBE AS | 1 | |
| 3779667 | 15 HOSE AS | 1 | |
| 3779668 | 16 HOSE AS | 1 | |
| 3902907 | 17 BRACKET | 1 | |
| 3982210 | 18 BRACKET | 1 | |
| 3982211 | 19 BLOCK | 1 | |
| 3982212 | 20 BRACKET | 1 | |
| 3982213 | 21 BRACKET | 1 | |
| 3982214 | 22 BLOCK | 1 | |
| 3982216 | 23 BRACKET | 1 | |
| 4878085 | 24 HOSE AS | 1 | |
| 0619593 | 25 ADAPTER | 1 | |
| 0909019 | 26 PLUG-PIPE (1-11-1/2 NPT THD) | 1 | |
| 0L2070 | 27 BOLT (3/8-16X2.25-IN) | 2 | |
| 1653931 | 28 BOLT (3/8-16X1.75-IN) | 2 | |
| 0S1588 | 29 BOLT (3/8-16X1.25-IN) | 2 | |
| 1653929 | 30 BOLT (3/8-16X1.5-IN) | 8 | |
| 0S1594 | 31 BOLT (3/8-16X1-IN) | 15 | |
| 1345645 | 32 CLIP | 2 | |
| 1448618 | 33 ADAPTER | 1 | |
| 1A2029 | 34 BOLT (3/8-16X1.125-IN) | 2 | |
| 1C2251 | 35 BOLT (3/8-16X1.87-IN) | 2 | |
| 1F7958 | 36 NUT-FULL (1/2-13-THD) | 2 | |
| 2721777 | 37 WASHER-HARD (11X18.5X15-MM THK) | 2 | |
| 2B0941 | 38 SPACER (10.5X19X19-MM THK) | 2 | |
| 2T2396 | 39 ELBOW | 1 | |
| 3159833 | 40 CONNECTOR | 1 | |
| 3B1915 | 41 BOLT (3/8-16X1.375-IN) | 2 | |
| 3D2824 | 42 SEAL-O-RING | 5 | |
| 3E2333 | 43 ELBOW | 1 | |
| 3J5390 | 44 PLUG (3/8-18-THD) | 1 | |
| 3K0360 | 45 SEAL-O-RING | 8 | |
| 4K8302 | 46 CLIP (LOOP) | 3 | |
| 5L4759 | 47 SEAL-O-RING | 1 | |
| 5M2894 | 48 WASHER-HARD (10.2X18.5X2.5-MM THK) | 39 | |
| 5P8245 | 49 WASHER-HARD (13.5X25.5X3-MM THK) | 6 | |
| 5P9299 | 50 CLIP (LOOP) | 4 | |
| 6H1717 | 51 BOLT (1/2-13X1.125-IN) | 1 | |
| 3537954 | 52 GROMMET | 2 | |
| 6V8397 | 53 SEAL-O-RING | 1 | |
| 6V8398 | 54 SEAL-O-RING | 21 | |
| 6V8637 | 55 CONNECTOR | 2 | |
| 6V8639 | 56 CONNECTOR | 6 | |
| 6V8714 | 57 CONNECTOR | 1 | |
| 6V8789 | 58 TEE | 1 | |
| 6V9002 | 59 ELBOW | 2 | |
| 6V9746 | 60 SEAL-O-RING | 4 | |
| 6V9830 | 61 CAP (ORFS) | 1 | |
| 6V9837 | 62 TEE-SWIVEL | 2 | |
| 7B3235 | 63 BOLT (1/2-13X1.375-IN) | 1 | |
| 7H1911 | 64 BOLT (1/2-13X9.375-IN) | 2 | |
| 7M8485 | 65 SEAL-O-RING | 1 | |
| 8C6868 | 66 CONNECTOR | 1 | |
| 8C6871 | 67 CONNECTOR | 1 | |
| 8C6872 | 68 CONNECTOR | 1 | |
| 8C6874 | 69 CONNECTOR | 1 | |
| 8T1889 | 70 CLIP (SLOT) | 2 | |
| 8T1890 | 71 CLIP (TAB) | 2 | |
| 8T5429 | 72 ELBOW | 2 | |
| 9S8752 | 73 NUT-FULL (3/8-16-THD) | 4 | |
| 5K9090 | 74 SEAL-O-RING | 1 |
