System And Components
527-8067 LINES GP-TURBOCHARGER WATERAN ATTACHMENT
Group No: 527-8067
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7N3297 | 1 COVER | 1 | |
| 7N3368 | 2 GASKET | 1 | |
| 7N7878 | 3 PLATE-COVER | 4 | |
| 1070744 | 4 BLOCK | 4 | |
| 1994673 | 5 CONNECTOR | 1 | |
| 2935523 | 6 HOSE AS | 1 | |
| 3419211 | 7 GASKET | 8 | |
| 3779659 | 8 HOSE AS | 2 | |
| 3779660 | 9 HOSE AS | 1 | |
| 3779661 | 10 TUBE AS | 1 | |
| 3779662 | 11 TUBE AS | 1 | |
| 3779663 | 12 HOSE AS | 2 | |
| 3779666 | 13 TUBE AS | 1 | |
| 3779668 | 14 HOSE AS | 1 | |
| 3902907 | 15 BRACKET | 1 | |
| 3982210 | 16 BRACKET | 1 | |
| 3982211 | 17 BLOCK | 1 | |
| 3982212 | 18 BRACKET | 1 | |
| 3982213 | 19 BRACKET | 1 | |
| 3982216 | 20 BRACKET | 1 | |
| 4878085 | 21 HOSE AS | 1 | |
| 5278069 | 22 HOSE AS-WATER | 1 | |
| 0619593 | 23 ADAPTER | 2 | |
| 0L2070 | 24 BOLT (3/8-16X2.25-IN) | 2 | |
| 1653931 | 25 BOLT (3/8-16X1.75-IN) | 2 | |
| 0S1588 | 26 BOLT (3/8-16X1.25-IN) | 2 | |
| 1653929 | 27 BOLT (3/8-16X1.5-IN) | 8 | |
| 0S1594 | 28 BOLT (3/8-16X1-IN) | 15 | |
| 1345645 | 29 CLIP (LOOP) | 2 | |
| 1400395 | 30 SPACER (10.74X17.14X11-MM THK) | 1 | |
| 1A2029 | 31 BOLT (3/8-16X1.125-IN) | 2 | |
| 1C2251 | 32 BOLT (3/8-16X1.87-IN) | 2 | |
| 1F7958 | 33 NUT-FULL (1/2-13-THD) | 2 | |
| 2721777 | 34 WASHER-HARD (11X18.5X15-MM THK) | 1 | |
| 2B0941 | 35 SPACER (10.5X19X19-MM THK) | 2 | |
| 2T2396 | 36 ELBOW | 1 | |
| 3159833 | 37 CONNECTOR | 1 | |
| 3537954 | 38 GROMMET | 2 | |
| 3B1915 | 39 BOLT (3/8-16X1.375-IN) | 2 | |
| 3D2824 | 40 SEAL-O-RING | 4 | |
| 3E2333 | 41 ELBOW | 1 | |
| 3J5390 | 42 PLUG (3/8-18-THD) | 1 | |
| 3K0360 | 43 SEAL-O-RING | 6 | |
| 4K8302 | 44 CLIP (LOOP) | 3 | |
| 5K9090 | 45 SEAL-O-RING | 2 | |
| 5L4759 | 46 SEAL-O-RING | 1 | |
| 5M2894 | 47 WASHER-HARD (10.2X18.5X2.5-MM THK) | 39 | |
| 5P8245 | 48 WASHER-HARD (13.5X25.5X3-MM THK) | 6 | |
| 5P9299 | 49 CLIP (LOOP) | 4 | |
| 6H1717 | 50 BOLT (1/2-13X1.125-IN) | 1 | |
| 6V8397 | 51 SEAL-O-RING | 1 | |
| 6V8398 | 52 SEAL-O-RING | 22 | |
| 6V8637 | 53 CONNECTOR | 1 | |
| 6V8639 | 54 CONNECTOR | 6 | |
| 6V8714 | 55 CONNECTOR | 1 | |
| 6V8789 | 56 TEE | 1 | |
| 6V9746 | 57 SEAL-O-RING | 3 | |
| 6V9830 | 58 CAP (ORFS) | 1 | |
| 6V9837 | 59 TEE-SWIVEL | 3 | |
| 7B3235 | 60 BOLT (1/2-13X1.375-IN) | 1 | |
| 7H1911 | 61 BOLT (1/2-13X9.375-IN) | 2 | |
| 8C6868 | 62 CONNECTOR | 1 | |
| 8C6871 | 63 CONNECTOR | 1 | |
| 8C6872 | 64 CONNECTOR | 2 | |
| 8C6874 | 65 CONNECTOR | 1 | |
| 8C6875 | 66 CONNECTOR | 1 | |
| 8T1889 | 67 CLIP (SLOT) | 2 | |
| 8T1890 | 68 CLIP (TAB) | 2 | |
| 8T5429 | 69 ELBOW | 2 | |
| 9S8752 | 70 NUT-FULL (3/8-16-THD) | 4 |
