System And Components
487-8084 LINES GP-AIRTURBOCHARGER TO AFTERCOOLER
Group No: 487-8084
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2W7111 | 1 FLANGE | 2 | |
| 4W3851 | 2 BRACKET | 2 | |
| 4W9725 | 3 GASKET | 2 | |
| 4W9726 | 4 FLANGE | 1 | |
| 7L4302 | 5 GASKET | 2 | |
| 1145275 | 6 ADAPTER | 1 | |
| 2086990 | 7 ELBOW | 1 | |
| 2086991 | 8 ELBOW | 1 | |
| 3307151 | 9 HOSE AS | 1 | |
| 0321267 | 10 CONNECTOR (STRAIGHT) | 1 | |
| 0321268 | 11 CONNECTOR (90-DEG) | 1 | |
| 0S1585 | 12 BOLT (1/2-13X1.5-IN) | 6 | |
| 0S1588 | 13 BOLT (3/8-16X1.25-IN) | 1 | |
| 1A2029 | 14 BOLT (3/8-16X1.125-IN) | 1 | |
| 1A5822 | 15 BOLT (1/2-13X2.75-IN) | 6 | |
| 5P8245 | 16 WASHER-HARD (13.5X25.5X3-MM THK) | 20 | |
| 5P8862 | 17 SEAL-O-RING | 2 | |
| 6V0826 | 18 GROMMET | 1 | |
| 6V2695 | 19 SEAL-O-RING | 4 | |
| 6V3917 | 20 SEAL-O-RING | 4 | |
| 7B3235 | 21 BOLT (1/2-13X1.375-IN) | 6 | |
| 8L2786 | 22 SEAL-O-RING | 1 | |
| 8T1889 | 23 CLIP (SLOT) | 1 | |
| 8T1890 | 24 CLIP (TAB) | 1 | |
| 9S4185 | 25 PLUG (3/4-16-THD) | 1 | |
| 9X6458 | 26 WASHER-HARD (10.2X22.5X3-MM THK) | 2 | |
| 0L1329 | 27 BOLT (1/2-13X3-IN) | 2 |
