System And Components
381-4713 ELBOW GP-EXHAUSTAN ATTACHMENT
Group No: 381-4713
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1W7810 | 1 GASKET-OUTLET | 1 | |
| 4W1478 | 2 SEAL GP-EXHAUST | 1 | |
| 7W2124 | 3 BRACKET | 2 | |
| 1091086 | 4 SPACER (18.5X29X6-MM THK) | 1 | |
| 1339315 | 5 CLAMP-BAND | 1 | |
| 8T0122 | NUT-FULL (1/4-28-THD) | 1 | |
| 1350171 | 6 SEAL-EXHAUST | 1 | |
| 1350172 | 7 RING-EXHAUST SEAL | 1 | |
| 1411732 | 8 HOUSING-EXHAUST BYPASS | 1 | |
| 1411747 | 9 SHIELD | 1 | |
| 1411751 | 10 GASKET | 1 | |
| 2193234 | 11 SEAL GP-EXHAUST | 1 | |
| 3039357 | 12 COUPLING | 1 | |
| 3052635 | 13 BRACKET AS | 1 | |
| 3065169 | 14 ELBOW AS-EXHAUST | 1 | |
| 3083813 | 15 BRACKET AS | 1 | |
| 3116494 | 16 ELBOW-EXHAUST | 1 | |
| 3136930 | 17 BRACKET AS (FRONT, LH) | 1 | |
| 3136932 | 18 BRACKET AS (FRONT, RH) | 1 | |
| 0S1587 | 19 BOLT (1/2-13X1.75-IN) | 2 | |
| 0S1588 | 20 BOLT (3/8-16X1.25-IN) | 2 | |
| 0V0375 | 21 BOLT (1/2-13X3.25-IN) | 4 | |
| 1A1460 | 22 BOLT (1/2-13X2-IN) | 3 | |
| 1F7958 | 23 NUT-FULL (1/2-13-THD) | 8 | |
| 1L4473 | 24 BUSHING-TERMINAL | 4 | |
| 3E2331 | 25 PLUG (M18X1.5-THD) | 1 | |
| 3E6916 | 26 NUT-FULL (3/8-16-THD) | 6 | |
| 4J4382 | 27 PLUG-PIPE (1/2-14-THD) | 2 | |
| 5M2894 | 28 WASHER-HARD (10.2X18.5X2.5-MM THK) | 4 | |
| 5P2603 | 29 STUD-TAPERLOCK (3/8-16X1.57-IN) | 4 | |
| 5P7128 | 30 BOLT-HIGH TEMPERATURE (3/8-16X2-IN) | 2 | |
| 5P8245 | 31 WASHER-HARD (13.5X25.5X3-MM THK) | 24 | |
| 7L6443 | 32 BOLT-HIGH TEMPERATURE (3/8-16X2.25-IN) | 2 | |
| 8C8491 | 33 WASHER-HARD (10.2X22X3-MM THK) | 4 | |
| 8M2295 | 34 BOLT (3/8-16X1.625-IN) | 2 | |
| 9S1366 | 35 BOLT (1/2-13X2.5-IN) | 1 | |
| 9S1374 | 36 BOLT (1/2-13X8-IN) | 2 | |
| 9S8752 | 37 NUT-FULL (3/8-16-THD) | 2 | |
| 9V0999 | 38 SPACER (13.8X30X50-MM THK) | 4 | |
| 9X8873 | 39 BOLT (1/2-13X2.25-IN) | 4 |
