System And Components
520-9524 LINES GP-AIRAN ATTACHMENT
Group No: 520-9524
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1P0661 | 1 SPRING | 1 | |
| 4P7233 | 2 GROMMET | 2 | |
| 2815916 | 3 ELBOW | 1 | |
| 3537956 | 4 GROMMET | 3 | |
| 3819070 | 5 HOSE AS-WATER | 1 | |
| 4344947 | 6 REGULATOR | 1 | |
| 4344954 | 7 BRACKET | 1 | |
| 5209521 | 8 HOSE AS | 1 | |
| 5209522 | 9 HOSE AS | 1 | |
| 5210622 | 10 ADAPTER | 1 | |
| 0S1588 | 11 BOLT (3/8-16X1.25-IN) | 3 | |
| 2065017 | 12 SPACER (11X20X5-MM THK) | 2 | |
| 2124174 | 13 LOCKWASHER | 2 | |
| 2N8142 | 14 TEE-SWIVEL | 1 | |
| 2P4437 | 15 CLAMP | 4 | |
| 3256994 | 16 CLIP (SLOT) | 1 | |
| 3256995 | 17 CLIP (TAB) | 1 | |
| 3B1915 | 18 BOLT (3/8-16X1.375-IN) | 2 | |
| 3K0360 | 19 SEAL-O-RING | 1 | |
| 3S5849 | 20 GASKET | 2 | |
| 5M2894 | 21 WASHER-HARD (10.2X18.5X2.5-MM THK) | 6 | |
| 8L6557 | 22 CONNECTOR | 4 | |
| 9S8752 | 23 NUT-FULL (3/8-16-THD) | 2 | |
| 9X6458 | 24 WASHER-HARD (10.2X22.5X3-MM THK) | 1 |
