134-5403 TURBOCHARGER GPPART OF 379-5355 TURBOCHARGER GP

Group No: 134-5403
Part NumberPart NameQty
1B51741 PLUG-PIPE7
1N32792 CLAMP AS (COMPRESSOR)1
10938563 CARTRIDGE GP-TURBOCHARGER1
2395894BEARING-JOURNAL1
4613754BEARING-JOURNAL (0.51-MM OS)2
4613757BEARING-JOURNAL (0.25-MM US)2
4613762BEARING-JOURNAL (0.25-MM OS, 0.25-MM US)2
4613767BEARING-JOURNAL (0.25-MM OS)2
4613778BEARING-JOURNAL (0.25-MM US, 0.51-MM OS)2
2112261BEARING-THRUST1
4P3818BOLT (M4X0.7X10-MM)3
4P3819BOLT (M6X1X22-MM)4
2234291COLLAR-THRUST1
9M8915RING-RETAINING3
2234288SEAL RING-PISTON2
2234289SEAL RING-PISTON1
2234287SEAL-RING1
4613792WASHER (WEAR)3
6N99104 HOUSING AS-TURBINE1
9N20385 CLAMP AS-TURBINE1
9Y70126 HOUSING-COMPRESSOR1
