System And Components
385-2501 CONTROL GP-CARBURETORS/N E8C1-UP
Group No: 385-2501
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2W5405 | 1 ROD | 1 | |
| 4P0708 | 2 LEVER | 1 | |
| 4W2290 | 3 SHAFT | 1 | |
| 4W4945 | 4 LEVER AS | 1 | |
| 4W4944 | LEVER-GOVERNOR | 1 | |
| 4W4946 | COVER AS | 1 | |
| 6B2730 | BEARING AS | 1 | |
| 5L3291 | 5 BEARING AS-BALL | 2 | |
| 6V8955 | 6 ROD END (BEARING) | 1 | |
| 6V9163 | 7 ROD END (BEARING) | 3 | |
| 7E9748 | 8 ROD END (BEARING) | 2 | |
| 4973911 | 9 GASKET (COVER) | 1 | |
| 9Y2636 | 10 LEVER | 1 | |
| 1149269 | 11 SLEEVE | 6 | |
| 1195092 | 12 ROD | 1 | |
| 1238679 | 13 ROD | 1 | |
| 1A2029 | 14 BOLT (3/8-16X1.125-IN) | 15 | |
| 1B7182 | 15 BOLT (5/16-18X1.25-IN) | 1 | |
| 1B8701 | 16 KEY-WOODRUFF | 2 | |
| 1D4538 | 17 BOLT (5/16-18X2.25-IN) | 1 | |
| 2W5404 | 18 LEVER | 1 | |
| 3B1915 | 19 BOLT (3/8-16X1.375-IN) | 2 | |
| 4B3388 | 20 BOLT (5/16-18X1.125-IN) | 5 | |
| 5M2894 | 21 WASHER-HARD (10.2X18.5X2.5-MM THK) | 15 | |
| 5S0003 | 22 NUT (5/16-18-THD) | 6 | |
| 6V8186 | 23 NUT-FULL (5/16-24-THD) | 3 | |
| 8L4496 | 24 NUT-JAM (5/16-24 LH-THD) | 3 | |
| 8T9658 | 25 SPACER (8.2X12.7X25.4-MM THK) | 1 | |
| 9M1974 | 26 WASHER-HARD (8.8X16X2-MM THK) | 5 | |
| 9S8752 | 27 NUT-FULL (3/8-16-THD) | 2 |
