System And Components
445-1457 SENSOR & MOUNTING GP -DRILL HEAD ENCODERPART OF 454-7525 MONITOR AR-DRILL
Group No: 445-1457
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3520481 | 1 ENCODER (DRILL HEAD) | 1 | |
| 3520483 | 2 COUPLING-FLEXIBLE | 1 | |
| 4157007 | 3 HARNESS AS-WIRING (BREAKOUT, ENCODER) | 1 | |
| 4451454 | 4 SUPPORT-BRACKET | 1 | |
| 4451455 | 5 SHAFT | 1 | |
| 4451456 | 6 COVER AS | 1 | |
| 6V9632 | NUT-WELD (M6X1-THD) | 4 | |
| 4451458 | 7 ADAPTER | 2 | |
| 4543344 | 8 COVER | 2 | |
| 4547528 | 9 COVER AS | 1 | |
| 6V9632 | NUT-WELD (M6X1-THD) | 6 | |
| 0S1588 | 10 BOLT (3/8-16X1.25-IN) | 3 | |
| 1219940 | 11 WASHER (4X8X0.5-MM THK) | 8 | |
| 1705632 | 12 BOLT (M4X0.7X16-MM) | 4 | |
| 5C8312 | 13 NUT (M4X0.7-THD) | 4 | |
| 5C9553 | 14 BOLT (M6X1X16-MM) | 12 | |
| 5P8439 | 15 GROMMET | 1 | |
| 6V5230 | 16 BOLT (M10X1.5X60-MM) | 2 | |
| 6V7744 | 17 LOCKNUT (M10X1.5-THD) | 2 | |
| 8T4896 | 18 WASHER-HARD (10.2X18.5X2.5-MM THK) | 4 | |
| 9X8256 | 19 WASHER (6.6X12X2-MM THK) | 12 |
