System And Components
463-7748 SENSOR & MOUNTING GP -ROTATIONPART OF 485-2738, 485-2761 MONITOR AR-DRILL
Group No: 463-7748
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3522586 | 1 BOLT-SPECIAL | 1 | |
| 3630347 | 2 SENSOR AS-ROTARY POSITION | 1 | |
| 2693277 | RING | 1 | |
| 3967666 | 3 SCREW-FLAT HEAD (M6X1X80-MM) | 2 | |
| 4157014 | 4 HARNESS AS-SENSOR (ROTATION SENSOR) | 1 | |
| 4543342 | 5 SPACER AS | 1 | |
| 4637746 | 6 COVER AS | 1 | |
| 4637747 | 7 ACTUATOR AS (ROTATION) | 1 | |
| 1360157 | 8 WASHER (8.4X15.5X1.6-MM THK) | 1 | |
| 5P4116 | 9 WASHER-HARD (8.8X20.5X2-MM THK) | 8 | |
| 6V3940 | 10 BOLT (M8X1.25X25-MM) | 4 | |
| 6V9189 | 11 LOCKNUT (M8X1.25-THD) | 4 | |
| 8T4136 | 12 BOLT (M10X1.5X25-MM) | 1 | |
| 8T4896 | 13 WASHER-HARD (10.2X18.5X2.5-MM THK) | 1 | |
| 8Y3795 | 14 BOSS (M10X1.5X40-MM) | 1 |
