System And Components
467-7058 SENSOR & MOUNTING GPAN ATTACHMENT
Group No: 467-7058
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3520481 | 1 ENCODER (DRILL HEAD) | 1 | |
| 3520483 | 2 COUPLING-FLEXIBLE | 1 | |
| 4451458 | 3 ADAPTER | 2 | |
| 4543344 | 4 COVER | 2 | |
| 4677052 | 5 COVER AS | 1 | |
| 4677053 | 6 DISC AS | 1 | |
| 4677054 | 7 BRACKET AS | 1 | |
| 4677055 | 8 COVER AS | 1 | |
| 0950741 | 9 SCREW-MACHINE (M6X1-THD) | 4 | |
| 1219940 | 10 WASHER (4X8X0.5-MM THK) | 8 | |
| 1705632 | 11 BOLT (M4X0.7X16-MM) | 4 | |
| 5C8312 | 12 NUT (M4X0.7-THD) | 4 | |
| 5C9553 | 13 BOLT (M6X1X16-MM) | 5 | |
| 5P8439 | 14 GROMMET | 1 | |
| 6V7744 | 15 LOCKNUT (M10X1.5-THD) | 2 | |
| 8T4185 | 16 BOLT (M10X1.5X50-MM) | 2 | |
| 8T4896 | 17 WASHER-HARD (10.2X18.5X2.5-MM THK) | 4 | |
| 9X8256 | 18 WASHER (6.6X12X2-MM THK) | 9 |
