System And Components
424-1476 PIPE GP-FLEXIBLE EXHAUSTS/N HWS1-UP
Group No: 424-1476
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0617208 | 1 CLAMP-TUBE | 2 | |
| 3595885 | 2 CLAMP AS | 1 | |
| 3790045 | 3 ANGLE | 1 | |
| 3811815 | 4 BRACKET | 1 | |
| 4228964 | 5 SUPPORT AS | 1 | |
| 4241482 | 6 TUBE AS | 1 | |
| 4244825 | 7 SLEEVE | 1 | |
| 4381730 | 8 TUBE AS | 1 | |
| 5P4116 | 9 WASHER-HARD (8.8X20.5X2-MM THK) | 6 | |
| 7X0578 | 10 WASHER-HARD (10.2X32X2.5-MM THK) | 1 | |
| 7X2543 | 11 BOLT (M10X1.5X120-MM) | 1 | |
| 8T4121 | 12 WASHER-HARD (11X21X2.5-MM THK) | 5 | |
| 8T4172 | 13 BOLT (M10X1.5X80-MM) | 1 | |
| 8T4186 | 14 BOLT (M10X1.5X40-MM) | 1 | |
| 8T4189 | 15 BOLT (M8X1.25X20-MM) | 2 | |
| 8T9515 | 16 BOLT-SOCKET HEAD (M10X1.5X40-MM) | 1 | |
| 9X2027 | 17 WASHER (11X18X2-MM THK) | 1 |
