Assembly
100%

468-7974 CONTROL GP-HYDRAULIC HAND -BACKHOES/N LYA1-UP

Group No: 468-7974
Part NumberPart NameQty
16413991 KNOB2
38564952 BRACKET AS1
1599539NUT-WELD (M6X1-THD)2
1599541NUT-WELD (M10X1.5-THD)2
38565053 BRACKET AS2
39836004 LEVER2
41793565 TIE ROD GP4
8T4133NUT (M10X1.5-THD)2
3039307ROD1
5371973BALL JOINT1
4357651BALL JOINT1
42590776 SEAL1
43099287 FILM-INSTRUCTION (BACKHOE)1
43735808 MOUNT4
43934959 PIN4
454009710 CLIP2
189535811 BOLT (M10X1.5X60-MM)4
3E800012 NUT-JAM (M16X1.5-THD)2
6V735713 BOLT (M6X1X25-MM)2
8T412114 WASHER-HARD (11X21X2.5-MM THK)4
8T413315 NUT (M10X1.5-THD)4
8T418916 BOLT (M8X1.25X20-MM)6
8T420517 WASHER-HARD (7.2X14.5X2-MM THK)2
8T422218 WASHER-PLATED (11X32X2.5-MM THK)4
8T422419 WASHER-HARD (8.8X16X2-MM THK)6
9R280720 CLIP (RETAINER)4
