System And Components
452-6389 WIRING GP-LIGHTING -LICENSE PLATES/N LYC1-UP
Group No: 452-6389
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3S2093 | 1 STRAP-CABLE | 7 | |
| 4P7582 | 2 CLIP (LADDER) | 1 | |
| 1409378 | 3 RELAY AS (12-VOLT)(REVERSE LIGHT) | 1 | |
| 2061345 | 4 STRAP-CABLE | 3 | |
| 2624728 | 5 LAMP GP-BACKUP (12-VOLT)(REVERSING) | 2 | |
| 9W3326 | LAMP (12-VOLT, 21-WATT)(MINIATURE) | 1 | |
| 3447955 | LENS (REVERSING) | 1 | |
| 4371159 | 6 LAMP GP-REGISTRATION PLATE | 1 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 20-GA) | 2 | |
| 1028802 | KIT-RECEPTACLE (2-PIN) | 1 | |
| 1303514 | LAMP (12-VOLT, 5-WATT)(REGISTRATION PLATE) | 1 | |
| 4481630 | 7 SPACER | 1 | |
| 4526387 | 8 HARNESS AS-LIGHTING | 1 | |
| 4566208 | 9 PLATE | 1 | |
| 5C2890 | 10 NUT (M6X1-THD) | 4 | |
| 8T4121 | 11 WASHER-HARD (11X21X2.5-MM THK) | 2 | |
| 8T4179 | 12 BOLT (M12X1.75X20-MM) | 1 | |
| 8T4205 | 13 WASHER-HARD (7.2X14.5X2-MM THK) | 4 | |
| 8T4223 | 14 WASHER-HARD (13.5X25.5X3-MM THK) | 1 | |
| 8T5005 | 15 BOLT (M10X1.5X70-MM) | 2 |
