System And Components
515-0084 CONTROL GP-HYDRAULIC HAND -PARALLEL LIFTS/N LYG1-UP
Group No: 515-0084
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8T4743 | 1 PIN | 3 | |
| 1641368 | 2 FASTENER (CLIP) | 5 | |
| 1641395 | 3 KNOB | 1 | |
| 2061345 | 4 STRAP-CABLE | 2 | |
| 3876680 | 5 CONTROL GP-HANDLE (MECHANICAL) | 1 | |
| 3887048 | 6 BRACKET AS | 1 | |
| 4492128 | 6A BUSHING | 1 | |
| 3897230 | 7 PIN | 1 | |
| 3897232 | 8 LEVER AS | 1 | |
| 3884733 | 8A BUSHING | 1 | |
| 3897244 | 9 PIN | 1 | |
| 3897277 | 10 LEVER AS | 1 | |
| 3884732 | 10A BUSHING | 1 | |
| 3908024 | 11 PIN AS | 1 | |
| 3908743 | 12 ROD AS | 1 | |
| 8T4133 | NUT (M10X1.5-THD) | 1 | |
| 8T4773 | BALL JOINT | 1 | |
| 9X2065 | NUT (M10X1.5-THD, LH) | 1 | |
| 4542225 | ROD | 1 | |
| 4543053 | BALL JOINT | 1 | |
| 3952917 | 13 PLATE | 1 | |
| 4152274 | 14 SEAL | 1 | |
| 4188607 | 15 ROD AS | 1 | |
| 8T4133 | NUT (M10X1.5-THD) | 1 | |
| 8T4773 | BALL JOINT | 1 | |
| 8T4815 | ROD END | 1 | |
| 3908742 | ROD AS | 1 | |
| 4188608 | 16 ROD AS | 1 | |
| 8T4133 | NUT (M10X1.5-THD) | 1 | |
| 8T4773 | BALL JOINT | 1 | |
| 8T4815 | ROD END | 1 | |
| 3908747 | ROD | 1 | |
| 4188609 | 17 ROD AS | 1 | |
| 8T4133 | NUT (M10X1.5-THD) | 2 | |
| 8T4773 | BALL JOINT | 1 | |
| 8T4815 | ROD END | 1 | |
| 3908822 | STUD (M10X1.5-MM) | 1 | |
| 4540097 | 18 CLIP | 5 | |
| 4640222 | 19 FILM-INSTRUCTION (LOADER CONTROL) | 1 | |
| 1382042 | 20 LOCKNUT (M10X1.5-THD) | 2 | |
| 1704735 | 21 RING-RETAINING | 5 | |
| 5H3193 | 22 PIN-SPRING | 1 | |
| 5P4116 | 23 WASHER-HARD (8.8X20.5X2-MM THK) | 2 | |
| 6V7744 | 24 LOCKNUT (M10X1.5-THD) | 4 | |
| 7X0510 | 25 WASHER-HARD (15.5X29X3-MM THK) | 1 | |
| 7X7729 | 26 WASHER (11X25X3-MM THK) | 2 | |
| 8T4121 | 27 WASHER-HARD (11X21X2.5-MM THK) | 5 | |
| 8T4136 | 28 BOLT (M10X1.5X25-MM) | 2 | |
| 8T4189 | 29 BOLT (M8X1.25X20-MM) | 2 |
