System And Components
473-2823 VALVE GP-AUXILIARY -8TH FUNCTIONS/N HWR1-UP
Group No: 473-2823
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8T4121 | 1 WASHER-HARD (11X21X2.5-MM THK) | 3 | |
| 8T4743 | 2 PIN | 2 | |
| 1798235 | 3 LOCK PIN | 1 | |
| 1845382 | 4 PIN | 1 | |
| 3856511 | 5 BUSHING | 2 | |
| 3883235 | 6 SUPPORT AS | 1 | |
| 3856511 | 6A BUSHING | 2 | |
| 3883237 | 7 SHAFT AS | 1 | |
| 3883240 | 8 SHAFT | 1 | |
| 3893098 | 9 VALVE GP-CONTROL (EXTENDABLE STICK) | 1 | |
| 3966355 | 10 PLATE | 2 | |
| 3968862 | 11 PEDAL AS (LH) | 1 | |
| 4428457 | 12 ROD AS | 1 | |
| 8T4133 | NUT (M10X1.5-THD) | 2 | |
| 8T4815 | ROD END | 2 | |
| 3883241 | ROD | 1 | |
| 4442165 | 13 SPACER | 2 | |
| 4595272 | 14 ROD AS | 1 | |
| 1107595 | 15 PIN-SPRING | 2 | |
| 1617632 | 16 BOLT-SELF-LOCKING (M10X1.5X40-MM) | 1 | |
| 4J9535 | 17 SEAL-O-RING | 1 | |
| 6V8978 | 18 SEAL-O-RING | 3 | |
| 6V9824 | 19 RING-RETAINING | 1 | |
| 8C7562 | 20 SCREW-FLAT HEAD (M8X1.25X20-MM) | 2 | |
| 8T0389 | 21 LOCKNUT (M10X1.5-THD) | 2 | |
| 3357519 | KIT-FASTENER (6-BANK) | 1 |
