System And Components
464-3222 FENDER GP-FRONT -4-WHEEL DRIVES/N LBF1-UP
Group No: 464-3222
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3775319 | 1 PLATE | 2 | |
| 4643226 | 2 BRACKET AS (LH) | 1 | |
| 4643227 | 3 BRACKET AS (RH) | 1 | |
| 9R2821 | BOSS (M10X1.5X15-MM) | 2 | |
| 4643253 | 4 FENDER (RH) | 1 | |
| 4643254 | 5 FENDER (LH) | 1 | |
| 6V7744 | 6 LOCKNUT (M10X1.5-THD) | 4 | |
| 8T4121 | 7 WASHER-HARD (11X21X2.5-MM THK) | 8 | |
| 8T4137 | 8 BOLT (M10X1.5X20-MM) | 4 | |
| 8T4140 | 9 BOLT (M16X2X60-MM) | 4 | |
| 8T4195 | 10 BOLT (M10X1.5X30-MM) | 4 | |
| 8T4222 | 11 WASHER-PLATED (11X32X2.5-MM THK) | 4 | |
| 9X8257 | 12 WASHER (17.5X30X3.5-MM THK) | 4 |
