388-3242 CONTROL GP-HYDRAULIC PEDAL -8TH FUNCTIONS/N LBF1-UP

Group No: 388-3242
Part NumberPart NameQty
8T47431 PIN2
17982352 LOCK PIN1
18453823 PIN1
38565114 BUSHING2
38832355 SUPPORT AS1
38565115A BUSHING2
38832376 SHAFT AS1
38832407 SHAFT1
39663558 PLATE2
39688629 PEDAL AS (LH)1
4429800PEDAL1
442845710 ROD AS1
8T4133NUT (M10X1.5-THD)2
8T4815ROD END2
3883241ROD1
444216511 SPACER2
459527212 ROD AS1
110759514 PIN-SPRING2
161763215 BOLT-SELF-LOCKING (M10X1.5X40-MM)1
6V982416 RING-RETAINING1
8C756217 SCREW-FLAT HEAD (M8X1.25X20-MM)2
8T038918 LOCKNUT (M10X1.5-THD)2
8T412120 WASHER-HARD (11X21X2.5-MM THK)3
