System And Components
364-1353 KIT-QUICK COUPLER CONVERSION -HYDRAULICS/N DSN1-UP
Group No: 364-1353
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7K1181 | 1 STRAP-CABLE | 2 | |
| 9X6581 | 2 NUT-O-RING SEAL (1-14-THD) | 1 | |
| 1242456 | 3 FILM-INSTRUCTION (NO STEP) | 1 | |
| 1922640 | 4 CYLINDER GP-HYDRAULIC (COUPLER) | 2 | |
| 1922645 | 5 SPRING | 2 | |
| 2079737 | 6 BRACKET AS | 1 | |
| 2079756 | 7 HOSE AS | 4 | |
| 2079785 | 8 PIN | 2 | |
| 2126521 | 9 SWITCH AS-ROCKER (QUICK COUPLER) | 1 | |
| 1117899 | GASKET | 1 | |
| 2126690 | 10 GUARD | 1 | |
| 2186245 | 11 HOSE AS | 2 | |
| 2186334 | 12 BRACKET AS | 1 | |
| 2186335 | 13 BRACKET AS | 1 | |
| 2194335 | 14 HOSE AS | 2 | |
| 2337128 | 15 MANIFOLD GP-CONTROL (QUICK COUPLER) | 1 | |
| 2520342 | 16 TUBE AS | 1 | |
| 2520343 | 17 TUBE AS | 1 | |
| 3038767 | 18 PIN-SPRING | 2 | |
| 3038768 | 19 PIN-SPRING | 4 | |
| 3106660 | 20 PIN-SPRING | 2 | |
| 3119240 | 21 PLATE | 2 | |
| 3155493 | 22 WASHER-HARD (22.5X35X4.5-MM THK) | 4 | |
| 3192137 | 23 BRACKET | 2 | |
| 3265762 | 24 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 4 | |
| 3265763 | 25 HOSE AS | 1 | |
| 1242113 | 26 COUPLING-PERMANENT | 1 | |
| 1242129 | 27 COUPLING-PERMANENT | 1 | |
| 1488325 | 28 CONNECTOR AS | 4 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 6V8641 | CONNECTOR | 1 | |
| 1488336 | 29 CONNECTOR AS | 2 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8636 | CONNECTOR | 1 | |
| 1488353 | 30 ELBOW AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V9001 | ELBOW | 1 | |
| 1488378 | 31 ELBOW AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8724 | ELBOW | 1 | |
| 1488433 | 32 TEE AS | 1 | |
| 6V8397 | SEAL-O-RING | 2 | |
| 6V9836 | TEE-SWIVEL | 1 | |
| 1488446 | 33 TEE AS-SWIVEL | 1 | |
| 6V9838 | TEE-SWIVEL | 1 | |
| 7J9108 | SEAL-O-RING | 2 | |
| 1504034 | 34 TEE AS | 2 | |
| 6V8397 | SEAL-O-RING | 3 | |
| 8T0379 | TEE-BULKHEAD | 1 | |
| 1564282 | 35 REDUCER AS | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8938 | REDUCER | 1 | |
| 2V3216 | 36 CLIP (LOOP) | 4 | |
| 3B4628 | 37 PIN-COTTER | 2 | |
| 3S2093 | 38 STRAP-CABLE | 1 | |
| 4P7581 | 39 CLIP (LADDER) | 1 | |
| 5P0372 | 40 LOCK PIN | 2 | |
| 6V8397 | 41 SEAL-O-RING | 4 | |
| 6V9168 | 42 NUT (11/16-16-THD) | 2 | |
| 7B1597 | 43 CLIP | 1 | |
| 7G2950 | 44 CLIP (SLOT) | 1 | |
| 7G2951 | 45 CLIP (TAB) | 1 | |
| 7H7055 | 46 CLIP | 2 | |
| 7X7729 | 47 WASHER (11X25X3-MM THK) | 4 | |
| 8L5188 | 48 PIN | 2 | |
| 8T4121 | 49 WASHER-HARD (11X21X2.5-MM THK) | 13 | |
| 8T4133 | 50 NUT (M10X1.5-THD) | 4 | |
| 8T4136 | 51 BOLT (M10X1.5X25-MM) | 1 | |
| 8T4189 | 52 BOLT (M8X1.25X20-MM) | 4 | |
| 8T4191 | 53 BOLT (M10X1.5X16-MM) | 2 | |
| 8T4196 | 54 BOLT (M10X1.5X35-MM) | 4 | |
| 8T4201 | 55 BOLT-LOCKING (M10X1.5X20-MM) | 3 | |
| 8T4224 | 56 WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 8T5005 | 57 BOLT (M10X1.5X70-MM) | 2 | |
| 9M8406 | 58 CLIP (LOOP) | 2 | |
| 9S1350 | 59 CLIP | 1 | |
| 9T7303 | 60 SPACER (16X28X1.5-MM THK) | 4 | |
| 2138702 | 61 HOSE-HYDRAULIC (66-IN) |
