System And Components
326-5678 LINES GP-LIFT CYLINDER -WITHOUT WORK TOOL POSITIONERS/N CD31-UP
Group No: 326-5678
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3E7404 | 1 CLAMP-HOSE | 2 | |
| 1121817 | 2 VALVE-BALL (HYDRAULIC LOCKOUT) | 1 | |
| 1428997 | 3 BLOCK | 2 | |
| 1783620 | 4 STRAP-DUAL CLAMP | 2 | |
| 1871273 | 5 TUBE AS | 2 | |
| 1873231 | 6 TUBE AS | 1 | |
| 1873232 | 7 TUBE AS | 1 | |
| 2185764 | 8 PLATE | 1 | |
| 2186438 | 9 SEAL | 1 | |
| 2859286 | 10 BLOCK | 1 | |
| 2903293 | 11 TUBE AS | 1 | |
| 3610458 | 12 TUBE AS | 1 | |
| 2903296 | 13 TUBE AS | 1 | |
| 2903301 | 14 TUBE AS | 1 | |
| 2903392 | 15 HOSE AS | 4 | |
| 3265614 | 16 HANDLE AS | 1 | |
| 3265625 | 17 BRACKET AS | 1 | |
| 1599539 | NUT-WELD (M6X1-THD) | 3 | |
| 1599540 | NUT-WELD (M8X1.25-THD) | 3 | |
| 3265634 | 18 BRUSH AS | 1 | |
| 3265689 | 19 HOSE AS | 1 | |
| 7X0579 | 20 WASHER-HARD (8.8X25.5X2-MM THK) | 1 | |
| 1488336 | 21 CONNECTOR AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8636 | CONNECTOR | 1 | |
| 1488341 | 22 CONNECTOR AS | 2 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V8713 | CONNECTOR | 1 | |
| 7J9108 | SEAL-O-RING | 1 | |
| 2719408 | 23 SCREW-TRUSS HEAD (M5X0.8X10-MM) | 1 | |
| 4B4863 | 24 WASHER (4.7X11X1.2-MM THK) | 4 | |
| 3T0851 | 25 LOCKNUT (M5X0.8-THD) | 2 | |
| 6V8398 | 26 SEAL-O-RING | 9 | |
| 7J9108 | 27 SEAL-O-RING | 6 | |
| 1166952 | 28 BOLT (M4X0.7X10-MM) | 4 | |
| 8T4121 | 29 WASHER-HARD (11X21X2.5-MM THK) | 2 | |
| 8T4136 | 30 BOLT (M10X1.5X25-MM) | 2 | |
| 8T4224 | 31 WASHER-HARD (8.8X16X2-MM THK) | 3 | |
| 8T4908 | 32 BOLT (M8X1.25X25-MM) | 3 | |
| 9X2043 | 33 SCREW-TRUSS HEAD (M6X1X14-MM) | 3 | |
| 8T0328 | 34 WASHER-HARD (5.5X10X1-MM THK) | 4 | |
| 1989706 | 35 SCREW-TRUSS HEAD (M5X0.8X16-MM) | 2 |
