System And Components
489-0361 MODULE GP-INTERFACE -AICMPART OF 489-0362 MODULE GP-INTERFACE
Group No: 489-0361
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3S2093 | 1 STRAP-CABLE | 10 | |
| 8C6354 | 2 CAP-RECEPTACLE (ET CONNECTOR) | 1 | |
| 1534816 | 4 WASHER-HARD (5.5X18X2-MM THK) | 4 | |
| 1635833 | 5 RELAY (24-VOLT)(FRONT, RH) | 1 | |
| 1635833 | 5A RELAY (24-VOLT)(FRONT, LH) | 1 | |
| 1635833 | 5B RELAY (24-VOLT)(REAR RH) | 1 | |
| 1635833 | 5C RELAY (24-VOLT)(REAR LH) | 1 | |
| 1635833 | 5D RELAY (24-VOLT)(HORN) | 1 | |
| 1635833 | 5E RELAY (24-VOLT)(SENSORS) | 1 | |
| 1395345 | 6 FUSE (5-AMPERE) | 6 | |
| 2235994 | 7 WASHER-SPRING | 4 | |
| 2246193 | 8 BOLT-SOCKET HEAD (M3X0.5X12-MM) | 4 | |
| 2514891 | 9 LOCKNUT (M6X1-THD) | 4 | |
| 2878955 | 10 NUT (M5X0.8-THD) | 14 | |
| 3055121 | 11 CLAMP | 2 | |
| 3187612 | 12 MODULE (TERMINAL, ELECTRONIC MODULE) | 4 | |
| 3187613 | 13 MODULE (TERMINAL, POWER MODULE) | 1 | |
| 3214472 | 14 MODULE-INTERFACE | 1 | |
| 3214473 | 15 MODULE-POWER | 1 | |
| 5497288 | 16 RELAY (2-AMPERE)(PARKING BRAKE) | 1 | |
| 5497288 | 16A RELAY (2-AMPERE)(ENGINE CONTROL MODULE) | 1 | |
| 5617044 | 18 RELAY AS (ENGINE CONTROL MODULE) | 1 | |
| 5617044 | 18A RELAY AS (PROGRAMMED) | 1 | |
| 5617044 | 18B RELAY AS (ENGINE ECM SWITCHED) | 1 | |
| 3290570 | RELAY (6-AMPERE) | 1 | |
| 4953002 | FUSE (6-AMPERE) | 1 | |
| 3386733 | 20 TERMINAL | 18 | |
| 3462579 | 21 CONTROLLER AS | 1 | |
| 3702289 | 23 CAP | 2 | |
| 4171152 | 30 MODULE GP-AUXILIARY RELAY | 3 | |
| 4171154 | 31 MODULE GP-INTERFACE | 1 | |
| 5617605 | 36 RELAY AS (RED) | 1 | |
| 5617605 | 36A RELAY AS (AMBER) | 1 | |
| 4322183 | RELAY (2-AMPERE)(CONTROL ACTION) | 1 | |
| 4953001 | FUSE (2-AMPERE) | 1 | |
| 4346708 | 37 MOUNT | 4 | |
| 8J2418 | 38 LOCKWASHER | 4 | |
| 4949545 | 46 HARNESS AS-CHASSIS (AICM) | 1 | |
| 9B1117 | 49 LOCKWASHER | 2 | |
| 0950736 | 50 SCREW-MACHINE (M5X0.8X10-MM) | 12 | |
| 0965486 | 51 SCREW-MACHINE (M6X1X25-MM) | 2 | |
| 0966166 | 52 WASHER-HARD (4.5X9X1-MM THK) | 3 | |
| 1153072 | 53 CLIP AS-CONNECTING (8-PIN) | 2 | |
| 1209027 | 54 SCREW-PAN HEAD (M3X0.5X16-MM) | 4 | |
| 1305300 | 55 CLIP | 3 | |
| 1316405 | 56 NUT-HEX (M2X0.4-THD) | 2 | |
| 2088469 | 58 LOCKNUT (M6X1-THD) | 4 | |
| 2235993 | 59 WASHER (6X12X1-MM THK) | 10 | |
| 2306375 | 60 BOLT (M5X0.8X12-MM) | 6 | |
| 2306376 | 61 WASHER-SPECIAL (5.5X10X1-MM THK) | 35 | |
| 3162770 | 62 WASHER (3X6X0.8-MM THK) | 15 | |
| 3214503 | 63 COVER | 2 | |
| 3290618 | 66 FLANGE | 1 | |
| 3354416 | 68 SCREW (M6X1.0X20-MM) | 4 | |
| 6V9671 | 70 SCREW-MACHINE (M3X0.5X12-MM) | 1 | |
| 6V9672 | 71 SCREW-MACHINE (M4X0.7X16-MM) | 1 | |
| 8T2658 | 72 LOCKNUT (M3X0.5-THD) | 8 | |
| 8T2659 | 73 LOCKNUT (M4X0.7-THD) | 3 | |
| 8T4127 | 74 SCREW-MACHINE (M5X0.8X20-MM) | 3 | |
| 8T6388 | 75 SCREW-MACHINE | 2 | |
| 7Y7389 | 76 SCREW (M5X0.8X16-MM) | 4 | |
| 8T8442 | 77 BOLT-SOCKET HEAD (M6X1X30-MM) | 4 | |
| 9X6153 | 78 BOLT (M6X1X10-MM) | 4 | |
| 9X8267 | 79 WASHER (6.6X12X2-MM THK) | 4 | |
| 3187724 | 81 DUCT (0.2-M) | ||
| 3187725 | 82 DUCT (0.1-M) | ||
| 3187725 | 82A DUCT (0.2-M) | ||
| 3055128 | 91 TERMINAL | 4 | |
| 3187723 | 92 RAIL (0.19-M EACH) |
