System And Components
365-4088 PANEL GP-ELECTRICALPART OF 434-7672, 434-7673 WIRING GP-PANEL
Group No: 365-4088
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0898034 | 1 SCREW-BUTTON HEAD | 2 | |
| 1005805 | 2 CAP-RECEPTACLE (3-PIN) | 1 | |
| 2264038 | 3 TAPE-REFLECTIVE | ||
| 2330059 | 4 FILM-WARNING (GROUND) | 1 | |
| 2459167 | 5 NUT (M4X0.7X5.5-MM) | 4 | |
| 2459168 | 6 WASHER (4.7X9X0.8-MM THK) | 24 | |
| 3033859 | 7 COVER-BOX | 1 | |
| 3214472 | 8 MODULE-INTERFACE | 1 | |
| 3234689 | 9 FILM-WARNING (SHOCK, ELECTROCUTION HAZARD) | 1 | |
| 3241944 | 10 CABLE AS | 1 | |
| 1257875 | TUBE-HEAT SHRINK (7.44-MM DIA)(10-CM) | ||
| 3343108 | 11 FILM-INSTRUCTION (AREA ISOLATION SYSTEM) | 1 | |
| 3386733 | 15 TERMINAL | 7 | |
| 3661743 | 16 CAP | 3 | |
| 3734736 | 17 FILM-IDENTIFICATION (ELECTRICAL PANEL) | 1 | |
| 0950723 | 33 SCREW-SPECIAL (M3X0.5X10-MM) | 4 | |
| 0960192 | 34 LOCKWASHER | 3 | |
| 0996418 | 35 NUT (M6X1-THD) | 4 | |
| 1209027 | 36 SCREW-PAN HEAD (M3X0.5X16-MM) | 4 | |
| 1504086 | 37 SCREW (M4X0.7X16-MM) | 4 | |
| 2038944 | 38 GASKET | 1 | |
| 2235993 | 39 WASHER (6X12X1-MM THK) | 7 | |
| 2306376 | 40 WASHER-SPECIAL (5.5X10X1-MM THK) | 10 | |
| 2606723 | 41 BOLT-SOCKET HEAD (M6X1X30-MM) | 1 | |
| 3033150 | 42 SCREW-PAN HEAD | 4 | |
| 3033844 | 43 ISOLATOR | 1 | |
| 3033860 | 44 BRACKET | 4 | |
| 3033861 | 45 LATCH | 1 | |
| 3055121 | 46 CLAMP | 9 | |
| 3055122 | 47 TERMINAL | 4 | |
| 3055128 | 48 TERMINAL | 8 | |
| 3132865 | 49 TERMINAL | 3 | |
| 3132867 | 50 TERMINAL | 7 | |
| 3162769 | 51 NUT (M3X0.5-THD) | 11 | |
| 3162770 | 52 WASHER (3X6X0.8-MM THK) | 15 | |
| 3187612 | 53 MODULE (TERMINAL, ELECTRONIC MODULE) | 2 | |
| 3187613 | 54 MODULE (TERMINAL, POWER MODULE) | 1 | |
| 3187645 | 55 CLIP | 3 | |
| 3214420 | 56 CONVERTER | 1 | |
| 3214465 | 57 SWITCH-PUSH BUTTON (SHUTDOWN RESET) | 1 | |
| 3214467 | 58 SWITCH-PUSH BUTTON (SHUTDOWN) | 1 | |
| 3214470 | 59 CIRCUIT BREAKER (2-AMPERE) | 6 | |
| 3214471 | 60 CIRCUIT BREAKER (6-AMPERE) | 1 | |
| 3214473 | 61 MODULE-POWER | 1 | |
| 3214474 | 62 MODULE | 1 | |
| 3214476 | 63 RELAY (2-AMPERE) | 1 | |
| 3214477 | 64 COVER | 1 | |
| 3214503 | 65 COVER | 2 | |
| 3214527 | 66 LINK | 6 | |
| 3214528 | 67 RELAY (24-VDC) | 2 | |
| 3214532 | 68 SEAL | 1 | |
| 3241840 | 69 MODULE | 1 | |
| 3B4503 | 71 LOCKWASHER | 6 | |
| 5C2874 | 72 NUT (M5X0.8-THD) | 1 | |
| 5C2890 | 73 NUT (M6X1-THD) | 2 | |
| 5C7261 | 74 NUT (M8X1.25-THD) | 4 | |
| 5W8686 | 75 WASHER (6X13X2-MM THK) | 4 | |
| 6V5215 | 76 BOLT (M8X1.25X16-MM) | 4 | |
| 6V9669 | 77 SCREW-MACHINE (M3X0.5X8-MM) | 3 | |
| 6V9673 | 78 SCREW-MACHINE (M5X0.8X12-MM) | 6 | |
| 8C3131 | 79 SEAL-O-RING | 3 | |
| 8T0334 | 80 WASHER-HARD (6.6X12.5X1.6-MM THK) | 1 | |
| 8T0337 | 81 SCREW-MACHINE (M4X0.7X12-MM) | 16 | |
| 8T2226 | 82 SCREW-MACHINE (M5X0.8X10-MM) | 3 | |
| 8T2659 | 83 LOCKNUT (M4X0.7-THD) | 4 | |
| 8T4205 | 84 WASHER-HARD (7.2X14.5X2-MM THK) | 3 | |
| 8T4224 | 85 WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 9X0145 | 86 RECEPTACLE AS-CONNECTOR (24-PIN) | 1 | |
| 9X4813 | 87 RECEPTACLE AS-CONNECTOR (3-PIN) | 1 | |
| 9X8256 | 88 WASHER (6.6X12X2-MM THK) | 1 | |
| 3187724 | 89 DUCT (0.28-M EACH) | ||
| 3187724 | 89A DUCT (0.3-M EACH) | ||
| 3187723 | 90 RAIL (0.2-M) | ||
| 3187723 | 90A RAIL (0.28-M) | ||
| 3S2093 | 91 STRAP-CABLE |
