System And Components
426-4901 SWITCH GP-SHUTDOWNPART OF 501-1462, 503-1889, 503-1890, 503-1891 KIT-INSTALLATION, 463-5628 SWITCH GP-SHUTDOWN
Group No: 426-4901
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3055121 | 1 CLAMP | 2 | |
| 3187612 | 2 MODULE (TERMINAL, ELECTRONIC MODULE) | 1 | |
| 3187613 | 3 MODULE (TERMINAL, POWER MODULE) | 1 | |
| 3214472 | 4 MODULE-INTERFACE | 1 | |
| 3214473 | 5 MODULE-POWER | 1 | |
| 3214474 | 6 MODULE | 1 | |
| 8T0328 | 7 WASHER-HARD (5.5X10X1-MM THK) | 4 | |
| 3386733 | 8 TERMINAL | 4 | |
| 8T4205 | 9 WASHER-HARD (7.2X14.5X2-MM THK) | 3 | |
| 4773244 | 10 INDICATOR (SHUTDOWN) | 1 | |
| 4820215 | 11 MODULE (COVER) | 1 | |
| 4820216 | 12 CONNECTOR | 1 | |
| 4820217 | 13 MOUNT | 1 | |
| 4820218 | 14 MOUNT | 1 | |
| 4820219 | 15 BEAD | 2 | |
| 4820220 | 16 CONNECTOR | 1 | |
| 4820221 | 17 MOUNT | 1 | |
| 4820222 | 18 BEAD | 1 | |
| 4820223 | 19 CONNECTOR | 1 | |
| 4820224 | 20 MODULE | 1 | |
| 5091864 | 21 GASKET | 1 | |
| 0965962 | 22 WASHER-HARD (3.4X7X0.8-MM THK) | 6 | |
| 1554098 | 23 SCREW-BUTTON HEAD (M3X0.5X1-MM) | 10 | |
| 2235993 | 24 WASHER (6X12X1-MM THK) | 3 | |
| 2606723 | 25 BOLT-SOCKET HEAD (M6X1X30-MM) | 1 | |
| 3B4503 | 26 LOCKWASHER | 2 | |
| 5C2890 | 27 NUT (M6X1-THD) | 2 | |
| 6V5698 | 28 SCREW-BUTTON HEAD (M4X0.7X10-MM) | 2 | |
| 6V9673 | 29 SCREW-MACHINE (M5X0.8X12-MM) | 2 | |
| 8C6364 | 30 BOLT-SOCKET HEAD (M5X0.8X14-MM) | 4 | |
| 3187723 | 31 RAIL (0.2-M) |
