System And Components
467-2742 INSTALLATION GP-TERRAINPART OF 467-2741 INSTALLATION GP-TERRAIN
Group No: 467-2742
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3890333 | 1 CABLE AS (ETHERNET) | 1 | |
| 2761456 | 2 COVER AS | 1 | |
| 2761457 | 3 BRACKET AS | 1 | |
| 6V9632 | NUT-WELD (M6X1-THD) | 4 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 8 | |
| 9X2032 | NUT-WELD (M4X0.7-THD) | 6 | |
| 3060184 | 4 PLATE | 1 | |
| 3255750 | 6 HARNESS AS-CONTROL (OUTSIDE CAB) | 1 | |
| 3828086 | 7 BRACKET AS | 1 | |
| 3828087 | 8 BRACKET AS | 1 | |
| 3828088 | 9 BRACKET | 1 | |
| 4580941 | 10 HARNESS AS-WIRING | 1 | |
| 1305300 | 11 CLIP | 1 | |
| 1325789 | 12 CLIP (LADDER) | 2 | |
| 2678828 | 13 GROMMET | 1 | |
| 3S2093 | 14 STRAP-CABLE | 4 | |
| 4P7581 | 15 CLIP (LADDER) | 7 | |
| 5P1076 | 16 WASHER-HARD (13.5X30X4-MM THK) | 4 | |
| 6D5729 | 17 GROMMET | 1 | |
| 6V5839 | 18 WASHER (11X21X2.5-MM THK) | 8 | |
| 6V6317 | 19 BOLT (M10X1.5X20-MM) | 8 | |
| 7K1181 | 20 STRAP-CABLE | 18 | |
| 8T4121 | 21 WASHER-HARD (11X21X2.5-MM THK) | 15 | |
| 8T4136 | 22 BOLT (M10X1.5X25-MM) | 10 | |
| 8T4183 | 24 BOLT (M12X1.75X40-MM) | 4 | |
| 8T4191 | 25 BOLT (M10X1.5X16-MM) | 1 | |
| 8T4194 | 26 BOLT (M12X1.75X50-MM) | 4 | |
| 8T4223 | 27 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 9X2043 | 28 SCREW-TRUSS HEAD (M6X1X14-MM) | 7 | |
| 7X7877 | 30 STRIP-EDGE (15-CM) | ||
| 3392854 | 31 PLUG-CONNECTOR | 1 |
