System And Components
460-8966 KIT-WIRING -VIMS 3GPART OF 494-9300, 494-9303 INSTALLATION GP-ONBOARD
Group No: 460-8966
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3S2093 | 1 STRAP-CABLE | 15 | |
| 7K1181 | 2 STRAP-CABLE | 15 | |
| 3438444 | 3 HARNESS AS-WIRING (BREAKOUT) | 1 | |
| 2L8075 | TERMINAL-RING (14-GA TO 16-GA, NO. 8 SCREW) | 2 | |
| 1028803 | KIT-RECEPTACLE (3-PIN) | 1 | |
| 8T8730 | SOCKET-CONNECTOR (16-GA TO 20-GA) | 6 | |
| 8T8737 | PLUG-SEAL | 3 | |
| 1152184 | CONNECTOR | 1 | |
| 1257874 | TUBE-HEAT SHRINK (5.72-MM DIA)(20-CM) | ||
| 1552260 | KIT-CONNECTING PLUG (3-PIN) | 2 | |
| 3438446 | 4 CABLE GP-BATTERY (5-FT)(MACHINE POWER TO CIRCUIT BRKR) | 1 | |
| 3438457 | 5 HARNESS AS-POWER (10-FT)(EXTENSION) | 1 | |
| 4339728 | 6 FILM-WARNING (EXPLOSION, WIRELESS, OMM, U.S.) | 1 | |
| 4339730 | 7 FILM-WARNING (EXPLOSION, WIRELESS, OMM, INTL) | 1 | |
| 4404685 | 8 HARNESS AS-WIRING (COMMUNICATION ADAPTER) | 1 | |
| 4509668 | 9 HARNESS AS-POWER (DISPLAY) | 1 | |
| 2D0388 | 10 GROMMET (25.4-MM ID) | 1 | |
| 6T3642 | 11 CIRCUIT BREAKER AS (10-AMPERE)(RESET) | 2 | |
| 6V8376 | SCREW-MACHINE (8-32X0.25-IN) | 2 | |
| 9B7233 | LOCKWASHER | 2 | |
| 5638091 | 12 HARNESS AS-MONITOR (ETHERNET ADAPTER) | 1 |
