System And Components
435-9502 WIRING GP-MONITOR -CMPDPART OF 447-0325 INSTALLATION AR-MONITOR SYSTEM
Group No: 435-9502
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7K1181 | 1 STRAP-CABLE | 37 | |
| 8T8737 | 2 PLUG-SEAL | 24 | |
| 2282844 | 3 COVER AS | 1 | |
| 5S0003 | NUT (5/16-18-THD) | 3 | |
| 9S8752 | NUT-FULL (3/8-16-THD) | 4 | |
| 3559048 | 4 DISPLAY GP-MONITOR (OBJECT DETECTION) | 1 | |
| 4346708 | 5 MOUNT | 4 | |
| 4381297 | 6 PLATE | 1 | |
| 4394835 | 7 CABLE AS | 1 | |
| 8T8730 | SOCKET-CONNECTOR (16-GA TO 18-GA) | 4 | |
| 3985357 | CABLE AS | 1 | |
| 4394836 | 8 HARNESS AS-MONITOR | 1 | |
| 4430283 | 9 CABLE AS | 1 | |
| 4532714 | 10 HARNESS AS-WIRING (BACKUP TIMER MODULE) | 1 | |
| 4534118 | 11 MODULE AS | 1 | |
| 4567723 | 12 HARNESS AS-CHASSIS | 1 | |
| 4582113 | 13 HARNESS AS-CAB | 1 | |
| 4583678 | 14 CABLE AS | 1 | |
| 4658773 | 15 PLATE | 1 | |
| 4660953 | 16 PLATE | 1 | |
| 4660954 | 17 MOUNT AS | 1 | |
| 5P7970 | NUT (M8X1.25-THD) | 2 | |
| 6V8225 | NUT (M6X1-THD) | 2 | |
| 4852243 | 18 BRACKET | 1 | |
| 4852245 | 19 CONNECTOR AS | 2 | |
| 4862465 | 20 HARNESS AS-CONTROL | 1 | |
| 0338248 | 21 CLIP | 1 | |
| 0966166 | 22 WASHER-HARD (4.5X9X1-MM THK) | 2 | |
| 1552256 | 23 KIT-CONNECTING PLUG (12-PIN) | 1 | |
| 1552257 | 24 KIT-CONNECTING PLUG (12-PIN) | 1 | |
| 2088469 | 25 LOCKNUT (M6X1-THD) | 4 | |
| 3290618 | 26 FLANGE | 1 | |
| 5M3062 | 27 BOLT (3/8-16X0.75-IN) | 3 | |
| 8T2502 | 28 BOLT (3/8-16X1.125-IN) | 4 | |
| 8T3998 | 29 BOLT (M4X0.7X12-MM) | 2 | |
| 8T4138 | 30 BOLT (M6X1X20-MM) | 6 | |
| 8T4171 | 31 BOLT (M6X1X12-MM) | 4 | |
| 8T4189 | 32 BOLT (M8X1.25X20-MM) | 2 | |
| 8T4205 | 33 WASHER-HARD (7.2X14.5X2-MM THK) | 10 | |
| 8T4224 | 34 WASHER-HARD (8.8X16X2-MM THK) | 3 | |
| 8T4896 | 35 WASHER-HARD (10.2X18.5X2.5-MM THK) | 7 | |
| 8T5391 | 36 BOLT (5/16-18X0.5-IN) | 1 | |
| 8T8908 | 37 BOLT (1/4-20X1-IN) | 2 | |
| 9X8256 | 38 WASHER (6.6X12X2-MM THK) | 2 | |
| 9X8267 | 39 WASHER (6.6X12X2-MM THK) | 4 |
