System And Components
470-8656 WIRING GP-MONITORPART OF 473-1579 INSTALLATION AR-MONITOR SYSTEM
Group No: 470-8656
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7K1181 | 1 STRAP-CABLE | 40 | |
| 8T8737 | 2 PLUG-SEAL | 24 | |
| 3559048 | 3 DISPLAY GP-MONITOR (OBJECT DETECTION) | 1 | |
| 4346708 | 4 MOUNT | 4 | |
| 4394835 | 5 CABLE AS | 1 | |
| 8T8730 | SOCKET-CONNECTOR (16-GA TO 18-GA) | 4 | |
| 4394836 | 6 HARNESS AS-MONITOR | 1 | |
| 4430283 | 7 CABLE AS | 1 | |
| 4534118 | 8 MODULE AS | 1 | |
| 4567723 | 9 HARNESS AS-CHASSIS | 1 | |
| 4582113 | 10 HARNESS AS-CAB | 1 | |
| 4583678 | 11 CABLE AS | 1 | |
| 4658773 | 12 PLATE | 1 | |
| 4660953 | 13 PLATE | 1 | |
| 4708652 | 14 HARNESS AS-WIRING | 1 | |
| 4708670 | 15 MOUNT AS | 1 | |
| 5P7970 | NUT (M8X1.25-THD) | 2 | |
| 6V8225 | NUT (M6X1-THD) | 2 | |
| 4708672 | 16 COVER AS | 1 | |
| 5P7970 | NUT (M8X1.25-THD) | 3 | |
| 4852243 | 17 BRACKET | 1 | |
| 4852245 | 18 CONNECTOR AS | 2 | |
| 4862465 | 19 HARNESS AS-CONTROL | 1 | |
| 0966166 | 20 WASHER-HARD (4.5X9X1-MM THK) | 2 | |
| 1305300 | 21 CLIP | 1 | |
| 1552256 | 22 KIT-CONNECTING PLUG (12-PIN) | 1 | |
| 1552257 | 23 KIT-CONNECTING PLUG (12-PIN) | 1 | |
| 2088469 | 24 LOCKNUT (M6X1-THD) | 4 | |
| 9X8267 | 25 WASHER (6.6X12X2-MM THK) | 4 | |
| 5M3062 | 26 BOLT (3/8-16X0.75-IN) | 3 | |
| 8T3998 | 27 BOLT (M4X0.7X12-MM) | 2 | |
| 8T4138 | 28 BOLT (M6X1X20-MM) | 6 | |
| 8T4171 | 29 BOLT (M6X1X12-MM) | 4 | |
| 8T4189 | 30 BOLT (M8X1.25X20-MM) | 2 | |
| 8T4205 | 31 WASHER-HARD (7.2X14.5X2-MM THK) | 10 | |
| 8T4224 | 32 WASHER-HARD (8.8X16X2-MM THK) | 3 | |
| 8T4896 | 33 WASHER-HARD (10.2X18.5X2.5-MM THK) | 3 | |
| 8T8908 | 34 BOLT (1/4-20X1-IN) | 2 | |
| 8T9043 | 35 BOLT (5/16-18X0.875-IN) | 1 | |
| 9X8256 | 36 WASHER (6.6X12X2-MM THK) | 2 |
