System And Components
474-3724 WIRING GP-MONITORPART OF 477-3076 INSTALLATION AR-MONITOR SYSTEM
Group No: 474-3724
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7K1181 | 1 STRAP-CABLE | 12 | |
| 8T8737 | 2 PLUG-SEAL | 24 | |
| 3559048 | 3 DISPLAY GP-MONITOR (OBJECT DETECTION) | 1 | |
| 4346708 | 4 MOUNT | 4 | |
| 4394835 | 5 CABLE AS | 1 | |
| 8T8730 | SOCKET-CONNECTOR (16-GA TO 18-GA) | 4 | |
| 4394836 | 6 HARNESS AS-MONITOR | 1 | |
| 4430283 | 7 CABLE AS | 1 | |
| 4534118 | 8 MODULE AS | 1 | |
| 4583678 | 9 CABLE AS | 1 | |
| 4658773 | 10 PLATE | 1 | |
| 4660953 | 11 PLATE | 1 | |
| 4660954 | 12 MOUNT AS | 1 | |
| 5P7970 | NUT (M8X1.25-THD) | 2 | |
| 6V8225 | NUT (M6X1-THD) | 2 | |
| 4743721 | 13 HARNESS AS-PANEL | 1 | |
| 4852243 | 14 BRACKET | 1 | |
| 4852245 | 15 CONNECTOR AS | 2 | |
| 4862465 | 16 HARNESS AS-CONTROL | 1 | |
| 0966166 | 17 WASHER-HARD (4.5X9X1-MM THK) | 2 | |
| 1552256 | 18 KIT-CONNECTING PLUG (12-PIN) | 1 | |
| 1552257 | 19 KIT-CONNECTING PLUG (12-PIN) | 1 | |
| 2088469 | 20 LOCKNUT (M6X1-THD) | 4 | |
| 5M3062 | 22 BOLT (3/8-16X0.75-IN) | 3 | |
| 8T3998 | 23 BOLT (M4X0.7X12-MM) | 2 | |
| 8T4138 | 24 BOLT (M6X1X20-MM) | 6 | |
| 8T4171 | 25 BOLT (M6X1X12-MM) | 4 | |
| 8T4189 | 26 BOLT (M8X1.25X20-MM) | 2 | |
| 8T4205 | 27 WASHER-HARD (7.2X14.5X2-MM THK) | 10 | |
| 8T4224 | 28 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 8T4896 | 29 WASHER-HARD (10.2X18.5X2.5-MM THK) | 3 | |
| 8T8908 | 30 BOLT (1/4-20X1-IN) | 2 | |
| 9X8256 | 31 WASHER (6.6X12X2-MM THK) | 2 | |
| 9X8267 | 32 WASHER (6.6X12X2-MM THK) | 4 |
