System And Components
485-0699 PANEL GP-INSTRUMENTS/N DXZ1-UP
Group No: 485-0699
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3S2093 | 1 STRAP-CABLE | 7 | |
| 9R7941 | 2 SOCKET AS | 1 | |
| 9R7980 | COVER | 1 | |
| 0844277 | 3 LAMP GP-DOME (12-VOLT) | 1 | |
| 1092356 | 4 PLUG | 4 | |
| 4678535 | 5 SWITCH AS-START (KEY) | 1 | |
| 7T6799 | NUT-MOUNTING (1-32-THD) | 1 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 20-GA) | 4 | |
| 1028804 | KIT-RECEPTACLE (4-PIN) | 1 | |
| 1429320 | 6 SWITCH AS-ROCKER (PARKING BRAKE) | 1 | |
| 1429328 | 7 SWITCH AS-ROCKER (FRONT WORK LIGHT) | 1 | |
| 1117899 | GASKET | 1 | |
| 1586694 | 8 PANEL | 1 | |
| 1586695 | 9 COVER | 1 | |
| 1586696 | 10 COVER | 1 | |
| 1586697 | 11 PANEL | 1 | |
| 1586698 | 12 COVER | 1 | |
| 1586699 | 13 COVER | 1 | |
| 2235941 | 14 SWITCH AS-ROCKER (WORK TOOL HYD PRESS RELEASE) | 1 | |
| 1117899 | GASKET | 1 | |
| 2236537 | 15 MODULE GP-WARNING INDICATOR (LH) | 1 | |
| 2265901 | 16 SWITCH AS-ROCKER (INTERLOCK OVERRIDE) | 1 | |
| 1117899 | GASKET | 1 | |
| 2492910 | 17 MODULE GP-WARNING INDICATOR (RH) | 1 | |
| 2584178 | 18 FLANGE-MOUNTING | 1 | |
| 3308684 | 19 LAMP AS (12-VOLT) | 1 | |
| 4781970 | 20 PLATE | 1 | |
| 4786310 | 21 HARNESS AS-PANEL | 1 | |
| 1032006 | 22 SCREW-PAN HEAD (6-19X0.37-IN) | 22 | |
| 1102028 | 23 SCREW-PAN HEAD (10-14X0.75-IN) | 4 | |
| 1706305 | 24 GAUGE GP-FUEL LEVEL (FUEL LEVEL) | 1 | |
| 4B2043 | NUT (8-32-THD) | 3 | |
| 7X9065 | LAMP (12-VOLT) | 1 | |
| 9B7233 | LOCKWASHER | 3 | |
| 1950936 | 25 INSERT-THREADED (M6X1-THD) | 4 | |
| 1976894 | 26 FILM-INSTRUCTION (INSTRUMENT PANEL) | 1 | |
| 1989707 | 27 SCREW-TRUSS HEAD (M6X1X35-MM) | 4 | |
| 4786314 | 28 FILM-IDENTIFICATION (PANEL SWITCHES) | 1 | |
| 4786316 | 29 FILM-INSTRUCTION (DASH) | 1 | |
| 9X2038 | 30 WASHER (7X19X2-MM THK) | 4 | |
| 9X2042 | 31 SCREW-TRUSS HEAD (M6X1X12-MM) | 6 | |
| 9X8256 | 32 WASHER (6.6X12X2-MM THK) | 4 |
