System And Components
378-3542 ELBOW GP-AIR INLETS/N D8T1-UP
Group No: 378-3542 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6I0917 | 1 BOLT (M6X1X25-MM) | 2 | |
| 1008451 | 2 BOLT (M8X1.25X130-MM) | 2 | |
| 1013895 | 3 BOLT (M8X1.25X35-MM) | 3 | |
| 1999751 | 4 SEAL-O-RING | 1 | |
| 3197840 | 5 GASKET (INLET ELBOW) | 1 | |
| 3426268 | 6 STUD (M8X1.25X80-MM) | 1 | |
| 3496804 | 7 BRACKET | 1 | |
| 3496805 | 8 PIPE-INLET | 1 | |
| 3545632 | 9 HOSE | 1 | |
| 3551079 | 10 CONNECTION | 1 | |
| 3565904 | 11 SPACER GP-AIR INLET | 1 | |
| 3469507 | 11A GASKET | 1 | |
| 3772854 | 12 MANIFOLD & VALVE GP | 1 | |
| 3T0849 | 12A BOLT-SOCKET HEAD (M6X1X25-MM) | 2 | |
| 3469501 | 12B GASKET | 1 | |
| 3469507 | 12C GASKET | 1 | |
| 3496734 | 12D VALVE GP-EXHAUST GAS (NRS) | 1 | |
| 3469508 | 12E SEAL | 1 | |
| 1783336 | 13 NUT-HEX FLANGE (M8X1.25-THD) | 1 | |
| 6I0456 | 14 BOLT (M8X1.25X45-MM) | 4 | |
| 6I0839 | 15 BOLT (M8X1.25X70-MM) | 2 | |
| 0358063 | 16 PLUG | 1 | |
| 1440367 | 17 CLAMP-HOSE | 2 | |
| 2321322 | 18 PLUG | 1 | |
| 3691658 | 19 SOLENOID (24-VOLT) | 1 |
