System And Components
393-4027 LINES GP-FUELS/N KNE1-UP
Group No: 393-4027 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3S2093 | 1 STRAP-CABLE | 1 | |
| 4I0379 | 2 VALVE-MANUAL (DRAIN, FUEL TANK) | 1 | |
| 5P6887 | 3 GROMMET | 1 | |
| 8D0482 | 4 GROMMET | 1 | |
| 0962916 | 5 GROMMET | 2 | |
| 2378510 | 6 GROMMET | 1 | |
| 2609244 | 7 ELBOW | 1 | |
| 3432410 | 8 BRACKET AS | 1 | |
| 3514335 | 9 GROMMET | 1 | |
| 3514336 | 10 GROMMET | 1 | |
| 3605510 | 11 FILTER GP-WATER SEP & FUEL | 1 | |
| 3617347 | 12 CONNECTION GP-FUEL | 2 | |
| 2287102 | SEAL-O-RING | 1 | |
| 3686658 | 13 VALVE | 1 | |
| 3848512 | 14 FILTER-FUEL (IN-LINE) | 1 | |
| 3855773 | 15 CONNECTOR AS | 2 | |
| 5P1046 | CONNECTOR | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 4172390 | 16 HOSE AS | 1 | |
| 4172392 | 17 HOSE AS | 1 | |
| 4172393 | 18 HOSE AS | 1 | |
| 4190692 | 19 HOSE | 1 | |
| 4465409 | 20 PUMP AS-FUEL TRANSFER (24-VOLT) | 1 | |
| 4509357 | 21 CAP-FUEL | 1 | |
| 4556811 | 22 HOSE AS | 1 | |
| 4611662 | 23 PLATE AS | 1 | |
| 1358573 | 24 BOLT AS | 3 | |
| 1485020 | 25 GROMMET | 1 | |
| 2147568 | 26 SEAL-O-RING | 2 | |
| 2385081 | 27 SEAL-O-RING | 1 | |
| 2977964 | 28 CONNECTOR | 2 | |
| 3295459 | 29 ADAPTER AS | 1 | |
| 5P1404 | ADAPTER | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 3309750 | 30 TEE AS | 1 | |
| 3E7410 | TEE | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 3474416 | 31 ADAPTER | 2 | |
| 3514318 | 32 CLIP (LOOP) | 22 | |
| 3514319 | 33 CLIP (LOOP) | 5 | |
| 3514320 | 34 CLIP (LOOP) | 12 | |
| 5P4325 | 35 CLIP (LOOP) | 1 | |
| 6S8620 | 36 CLAMP-HOSE | 13 | |
| 7V6571 | 37 GROMMET | 3 | |
| 8T1889 | 38 CLIP (SLOT) | 3 | |
| 8T1890 | 39 CLIP (TAB) | 3 | |
| 8T4121 | 40 WASHER-HARD (11X21X2.5-MM THK) | 37 | |
| 8T4136 | 41 BOLT (M10X1.5X25-MM) | 12 | |
| 8T4137 | 42 BOLT (M10X1.5X20-MM) | 20 | |
| 8T4196 | 43 BOLT (M10X1.5X35-MM) | 5 | |
| 8T4224 | 44 WASHER-HARD (8.8X16X2-MM THK) | 3 | |
| 8T6912 | 45 BOLT (M8X1.25X50-MM) | 3 | |
| 8C3681 | 46 HOSE-DRAIN (47.5-CM) | ||
| 3478646 | 47 HOSE (20-CM) | ||
| 3478645 | 48 HOSE (100.5-CM) | ||
| 3478645 | 48A HOSE (120-CM) | ||
| 3478645 | 48B HOSE (35-CM) | ||
| 3478645 | 48C HOSE (49.5-CM) |
