System And Components
358-0781 PUMP GP-FUEL INJECTIONS/N D8T1-UP
Group No: 358-0781 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3599666 | 1 BOLT-FLANGE HEAD (M8X1.25X130-MM) | 1 | |
| 2774223 | 2 PLUG | 1 | |
| 3228408 | 3 GEAR (36-TEETH) | 1 | |
| 3303036 | 4 GASKET | 1 | |
| 3316254 | 5 SPACER-SPECIAL | 1 | |
| 3317337 | 6 PLATE | 1 | |
| 3388797 | 7 LINE AS-FUEL | 1 | |
| 3689041 | 8 PUMP GP-FUEL INJECTION | 1 | |
| 3373905 | 8A SENSOR-TEMPERATURE (FUEL TEMPERATURE) | 1 | |
| 3582586 | 8B VALVE-CONTROL | 1 | |
| 1783336 | 9 NUT-HEX FLANGE (M8X1.25-THD) | 2 | |
| 1113422 | 10 NUT (M14X1.5-THD) | 1 | |
| 1113423 | 11 WASHER | 1 | |
| 3316841 | 13 BOLT (M8X1.25X30-MM) | 3 | |
| 6I0645 | 14 BOLT (M8X1.25X25-MM) | 4 | |
| 6I0840 | 15 STUD (M8X20-MM) | 2 | |
| 6V8676 | 16 SEAL-O-RING | 1 | |
| 5W1437 | 17 LOCKWASHER | 3 | |
| 6I0217 | 18 BOLT (M8X1.25X20-MM) | 1 | |
| 3708376 | KIT-FUEL SYSTEM PARTS | 1 |
